Danfoss Ally User Manual

29
BC349733524454en-010401 © Danfoss | FEC | 2023.06 |
User Guide Danfoss Ally™ Power Module 24V
12.2 Technical Specifications
Danfoss Ally™ Protect RA
Product type Tamper proof shell
Recommended use
For electronic thermostatic radiator valve
controllers
Adaptor mounting Compatible with a standard RA adaptor
Lifetime Mount / Dismount around 10 times in a lifetime
Bending strength 500N or 50 kg
Color RAL 7035
Type of materials (Base/Shell/Screw) ABS / ABS / Steel, zinc blue plated
Weight 47 g
Size 100x60 mm
Approvals, markings etc.
13. Danfoss Ally™ Power Module 24V
Danfoss Ally™ Power Module 24V is an
accessory that connects the electronic
radiator thermostat to a 24V power system in
the building and enables the device to work
without batteries. The power output must be
a 24 V supply from a safe source with a class
II insulation level (Power supply with built-in
double or reinforced insulation level between
the supply voltage and safe voltage).
Danfoss Ally™ Power Module 24V can be used
with both Danfoss Ally™ electronic Radiator
Thermostats and Danfoss Eco™, as well as in
combination with the Danfoss Ally™ Protect
RA for electronic radiator thermostats.
Danfoss Ally™ Power Module 24V does not
affect the efficiency of the Danfoss electronic
radiator thermostats.

Danfoss Ally Specifications

General

Accuracy	50 sec/month
Noise level	30 dB
Product color	White
Smart thermostat	Yes
Operating frequency	2400 MHz
Suitable for indoor use	-
Maximum water temperature	90 °C
Storage temperature (T-T)	-20 - 65 °C
Temperature control range	5 - 35 °C
Operating temperature (T-T)	0 - 40 °C
International Protection (IP) code	IP20
Package weight	250 g
Display type	LCD
Battery type	AA
Power consumption (typical)	1.2 W

Weight and Dimensions

Weight	198 g
Diameter	55 mm
