Danfoss Ally User Manual

25
BC349733524454en-010401 © Danfoss | FEC | 2023.06 |
User Guide Danfoss Ally™ Room Sensor
10.2 Technical Specifications
Danfoss Ally™ Room Sensor
Thermostat type Room Sensor
Recommended use Residential and light commercial buildings
Display LED indicator
Power supply CR2450 battery
Trasmission Frequency/Power 2,4 GHz/ <10 dBm EIRP (PSD)
Battery life Up to 5 years
Temperature detection range -20°C to 60°C
Weight (incl. battery) 25 g
IP class 20
Integrations* Partner API, Google Assistant, Amazon Alexa
Approvals, markings etc.
* Requires the Danfoss Ally™ Gateway.
10.3 Installation
Step 1.
Before mounting the sensor, choose correct location in
the room following the next recommendations:
• 1,5 m minimum height from the floor surface.
• 0,5 m minimum distance to the doors and windows.
Please note, avoid placing the sensor in direct sunlight!
Step 2.
Remove the battery insulation plastic once the sensor
is mounted on the wall. The LED will be flashing after
power up.

Danfoss Ally Specifications

General

Accuracy	50 sec/month
Noise level	30 dB
Product color	White
Smart thermostat	Yes
Operating frequency	2400 MHz
Suitable for indoor use	-
Maximum water temperature	90 °C
Storage temperature (T-T)	-20 - 65 °C
Temperature control range	5 - 35 °C
Operating temperature (T-T)	0 - 40 °C
International Protection (IP) code	IP20
Package weight	250 g
Display type	LCD
Battery type	AA
Power consumption (typical)	1.2 W

Weight and Dimensions

Weight	198 g
Diameter	55 mm
