User Guide Danfoss Icon™/Icon2™
Step 2.
Choose Danfoss Icon2™ from the list.
Step 3.
Press and hold the ‘OK’ button to iniate pairing process.
Step 4.
The LED above ‘>’ button will start to blink rapidly while
searching for a gateway.

Danfoss Ally Specifications

General

Accuracy	50 sec/month
Noise level	30 dB
Product color	White
Smart thermostat	Yes
Operating frequency	2400 MHz
Suitable for indoor use	-
Maximum water temperature	90 °C
Storage temperature (T-T)	-20 - 65 °C
Temperature control range	5 - 35 °C
Operating temperature (T-T)	0 - 40 °C
International Protection (IP) code	IP20
Package weight	250 g
Display type	LCD
Battery type	AA
Power consumption (typical)	1.2 W

Weight and Dimensions

Weight	198 g
Diameter	55 mm
