Installation and User Guide DEVIreg™ Multi
FEC | Produced by Danfoss ©38
Q1 Channel #1 > Regulation Type
P1 #1 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
0 1 1 – 1S Enum 1 RW 3008
Q2 Channel #1 > Temp & Hysteresis
P2 #1 Set Temperature -50 200 5 °C RW 3009
P3 #1 Set +-Hysteresis 0.2 6 0.4 °C RW 3010
Q3 Channel #1 > On Time & Period
P4 #1 Set On Time 1 0 15 min. RW 3011
P5 #1 Set PR Period (max. 900 minutes) 0 900 30 min. RW 3012
Q4 Channel #1 > Alarm Temps & En/Dis
P6 #1 Alarm Temp En/Dis 0 1 0 – Dis Enum 5 RW 3013
P7 #1 Alarm min. Temp -50 0 0 °C RW 3014
P8 #1 Alarm max. Temp 0 200 60 °C RW 3015
Q5 Channel #1 > CableOK?
P9 #1 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
0 1 0 – Dis Enum 5 RW 3016
P10 #1 CableOK? = NO/NC. Set up DI1 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
0 1 1 – NO Enum 8 RW 3017
Q75 Power calculator > Channel Power #1
P11 #1 Channel Power (max. 32000) 0 32000 0 W RW 3018
Q8 Channel #1 > Manually On/Of
P12 #1 Manually On/Of Time – Set up period of time
for MOn or MOf status (max. 900 minutes)
1 900 1 min. RW 3019
P13 #1 Status On or Of for mode Heating Manually 0 1 0 – Of Enum 11 RW 3020
P14 #1 Manually On/Of Start or Stop control mode.
Caution: this mode may cause overheating and
damage!
0 1 0 – STOP Enum 6 RW 3021
Q9 Channel #1 > Channel ON/OFF
P15 #1 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp. is
being shown
0 1 0 – OFF Enum 7 RW 3022
Q11 Channel #1 > Sensor type
P17 #1 Sensor type 0 7 1 – PT1000 Enum 9 RW 3023
Q12 Channel #1 > Relay Status RO/RC
P18 #1 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status ‘Heating On’
0 1 0 – RC Enum 10 RW 3024
Q13 Channel #1 > Relay Test 5/30 sec.
P19 #1 Relay Test 5/30 - Every 5 sec. switching for 30 sec. 0 1 0 – STOP Enum 6 RW 3025
W1 Channel #2 > Regulation Type
O1 #2 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
0 1 1 – 1S Enum 1 RW 3026
W2 Channel #2 > Temp & Hysteresis
O2 #2 Set Temperature -50 200 5 °C RW 3027
O3 #2 Set +-Hysteresis 0.2 6 0.4 °C RW 3028
W3 Channel #2 > On Time & Period
