FEC | Produced by Danfoss © 41
U11 #4 Channel Power (max. 32000) 0 32000 0 W RW 3072
G8 Channel #4 > Manually On/Of
U12 #4 Manually On/Of Time – Set up period of time
for MOn or MOf status (max. 900 minutes)
1 900 1 min. RW 3073
U13 #4 Status On or Of for mode Heating Manually 0 1 0 – Of Enum 11 RW 3074
U14 #4 Manually On/Of Start or Stop control mode.
Caution: this mode may cause overheating and
damage!
0 1 0 – STOP Enum 6 RW 3075
G9 Channel #4 > Channel ON/OFF
U15 #4 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp. is
being shown
0 1 0 – OFF Enum 7 RW 3076
G11 Channel #4 > Sensor type
U17 #4 Sensor type 0 7 1 – PT1000 Enum 9 RW 3077
G12 Channel #4 > Relay Status RO/RC
U18 #4 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status ‘Heating On’
0 1 0 – RC Enum 10 RW 3078
G13 Channel #4 > Relay Test 5/30 sec.
U19 #4 Relay Test 5/30 - Every 5 sec. switching for 30 sec. 0 1 0 – STOP Enum 6 RW 3079
H1 Channel #5 > Regulation Type
Y1 #5 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
0 1 1 – 1S Enum 1 RW 3080
H2 Channel #5 > Temp & Hysteresis
Y2 #5 Set Temperature -50 200 5 °C RW 3081
Y3 #5 Set +-Hysteresis 0.2 6 0.4 °C RW 3082
H3 Channel #5 > On Time & Period
Y4 #5 Set On Time 1 0 15 min. RW 3083
Y5 #5 Set PR Period (max. 900 minutes) 0 900 30 min. RW 3084
H4 Channel #5 > Alarm Temps & En/Dis
Y6 #5 Alarm Temp En/Dis 0 1 0 – Dis Enum 5 RW 3085
Y7 #5 Alarm min. Temp -50 0 0 °C RW 3086
Y8 #5 Alarm max. Temp 0 200 60 °C RW 3087
H5 Channel #5 > CableOK?
Y9 #5 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
0 1 0 – Dis Enum 5 RW 3088
Y10 #5 CableOK? = NO/NC. Set up DI5 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
0 1 1 – NO Enum 8 RW 3089
H75 Power calculator > Channel Power #5
Y11 #5 Channel Power (max. 32000) 0 32000 0 W RW 3090
H8 Channel #5 > Manually On/Of
Y12 #5 Manually On/Of Time – Set up period of time
for MOn or MOf status (max. 900 minutes)
1 900 1 min. RW 3091
Y13 #5 Status On or Of for mode Heating Manually 0 1 0 – Of Enum 11 RW 3092
