Installation and User Guide DEVIreg™ Multi
FEC | Produced by Danfoss ©40
R5 Channel #3 > CableOK?
I9 #3 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
0 1 0 – Dis Enum 5 RW 3052
I10 #3 CableOK? = NO/NC. Set up DI3 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
0 1 1 – NO Enum 8 RW 3053
R75 Power calculator > Channel Power #3
I11 #3 Channel Power (max. 32000) 0 32000 0 W RW 3054
R8 Channel #3 > Manually On/Of
I12 #3 Manually On/Of Time – Set up period of time
for MOn or MOf status (max. 900 minutes)
1 900 1 min. RW 3055
I13 #3 Status On or Of for mode Heating Manually 0 1 0 – Of Enum 11 RW 3056
I14 #3 Manually On/Of Start or Stop control mode.
Caution: this mode may cause overheating and
damage!
0 1 0 – STOP Enum 6 RW 3057
R9 Channel #3 > Channel ON/OFF
I15 #3 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp. is
being shown
0 1 0 – OFF Enum 7 RW 3058
R11 Channel #3 > Sensor type
I17 #3 Sensor type 0 7 1 – PT1000 Enum 9 RW 3059
R12 Channel #3 > Relay Status RO/RC
I18 #3 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status ‘Heating On’
0 1 0 – RC Enum 10 RW 3060
R13 Channel #3 > Relay Test 5/30 sec.
I19 #3 Relay Test 5/30 - Every 5 sec. switching for 30 sec. 0 1 0 – STOP Enum 6 RW 3061
G1 Channel #4 > Regulation Type
U1 #4 Regulation Type: 1S – Single Sensor, PR –
Power Regulation
0 1 1 – 1S Enum 1 RW 3062
G2 Channel #4 > Temp & Hysteresis
U2 #4 Set Temperature -50 200 5 °C RW 3063
U3 #4 Set +-Hysteresis 0.2 6 0.4 °C RW 3064
G3 Channel #4 > On Time & Period
U4 #4 Set On Time 1 0 15 min. RW 3065
U5 #4 Set PR Period (max. 900 minutes) 0 900 30 min. RW 3066
G4 Channel #4 > Alarm Temps & En/Dis
U6 #4 Alarm Temp En/Dis 0 1 0 – Dis Enum 5 RW 3067
U7 #4 Alarm min. Temp -50 0 0 °C RW 3068
U8 #4 Alarm max. Temp 0 200 60 °C RW 3069
G5 Channel #4 > CableOK?
U9 #4 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
0 1 0 – Dis Enum 5 RW 3070
U10 #4 CableOK? = NO/NC. Set up DI4 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
0 1 1 – NO Enum 8 RW 3071
G75 Power calculator > Channel Power #4
