Installation and User Guide DEVIreg™ Multi
FEC | Produced by Danfoss © 43
Z11 Channel #6 > Sensor type
T17 #6 Sensor type 0 7 1 – PT1000 Enum 9 RW 3113
Z12 Channel #6 > Relay Status RO/RC
T18 #6 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status ‘Heating On’
0 1 0 – RC Enum 10 RW 3114
Z13 Channel #6 > Relay Test 5/30 sec.
T19 #6 Relay Test 5/30 - Every 5 sec. switching for 30 sec. 0 1 0 – STOP Enum 6 RW 3115
X1 Channel #7 > Regulation Type
V1 #7 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
0 1 1 – 1S Enum 1 RW 3116
X2 Channel #7 > Temp & Hysteresis
V2 #7 Set Temperature -50 200 5 °C RW 3117
V3 #7 Set +-Hysteresis 0.2 6 0.4 °C RW 3118
X3 Channel #7 > On Time & Period
V4 #7 Set On Time 1 0 15 min. RW 3119
V5 #7 Set PR Period (max. 900 minutes) 0 900 30 min. RW 3120
X4 Channel #7 > Alarm Temps & En/Dis
V6 #7 Alarm Temp En/Dis 0 1 0 – Dis Enum 5 RW 3121
V7 #7 Alarm min. Temp -50 0 0 °C RW 3122
V8 #7 Alarm max. Temp 0 200 60 °C RW 3123
X5 Channel #7 > CableOK?
V9 #7 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
0 1 0 – Dis Enum 5 RW 3124
V10 #7 CableOK? = NO/NC. Set up DI7 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
0 1 1 – NO Enum 8 RW 3125
X75 Power calculator > Channel Power #7
V11 #7 Channel Power (max. 32000) 0 32000 0 W RW 3126
X8 Channel #7 > Manually On/Of
V12 #7 Manually On/Of Time – Set up period of time
for MOn or MOf status (max. 900 minutes)
1 900 1 min. RW 3127
V13 #7 Status On or Of for mode Heating Manually 0 1 0 – Of Enum 11 RW 3128
V14 #7 Manually On/Of Start or Stop control mode.
Caution: this mode may cause overheating and
damage!
0 1 0 – STOP Enum 6 RW 3129
X9 Channel #7 > Channel ON/OFF
V15 #7 Channel ON/OFF If OFF symbol # on the
main screen, algorithm is stopped, but real
Temp. is shown
0 1 0 – OFF Enum 7 RW 3130
X11 Channel #7 > Sensor type
V17 #7 Sensor type 0 7 1 – PT1000 Enum 9 RW 3131
X12 Channel #7 > Relay Status RO/RC
V18 #7 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status ‘Heating On’
0 1 0 – RC Enum 10 RW 3132
X13 Channel #7 > Relay Test 5/30 sec.
V19 #7 Relay Test 5/30 - Every 5 sec. switching for 30 sec. 0 1 0 – STOP Enum 6 RW 3133
