Dimensions
Tandem model Composition
L D H L1 H1
Outline drawing number
mm inch mm inch mm inch mm inch mm inch
DSH180E DSH090 + DSH090 850 33.46 384 15.12 507 19.96
240
min
9.45
min
242 9.53

8560115
DSH195U DSH090 + DSH105 850 33.46 386 15.20 565 22.24

8556233
DSH210U DSH090 + DSH120 850 33.46 386 15.20 565 22.24

8556233
DSH210E DSH105 + DSH105 850 33.46 384 15.12 565 22.24

8560114
DSH230U DSH090 + DSH140 850 33.46 386 15.20 565 22.24

8556233
DSH240E DSH120 + DSH120 850 33.46 384 15.12 565 22.24

8560114
DSH251U DSH090 + DSH161 850 33.46 386 15.20 565 22.24

8556233
DSH260U DSH140 + DSH120 850 33.46 386 15.20 565 22.24

8556230
DSH274U DSH090 + DSH184 850 33.46 428 16.85 580 22.83

8556232
DSH281U DSH161 + DSH120 850 33.46 386 15.20 565 22.24

8556230
DSH280E DSH140 + DSH140 850 33.46 384 15.12 565 22.24

8560114
DSH289U DSH105 + DSH184 850 33.46 428 16.85 580 22.83

8556231
DSH301U DSH161 + DSH140 850 33.46 386 15.20 565 22.24

8556230
DSH304U DSH120 + DSH184 850 33.46 428 16.85 580 22.83

8556231
DSH322E DSH161 + DSH161 850 33.46 384 15.12 565 22.24

8560114
DSH324U DSH140 + DSH184 850 33.46 428 16.85 580 22.83

8556231
DSH345U DSH161 + DSH184 850 33.46 428 16.85 580 22.83

8556231
DSH368E DSH184 + DSH184 850 33.46 428 16.85 580 22.83

8560113
DSH360X DSH120 + DSH240 903 35.55 533 20.98 731 28.78
359
min
14.13
min
211 8.31

8560128
DSH424X DSH184 + DSH240 903 35.55 533 20.98 731 28.78

8556259
DSH456X DSH161 + DSH295 903 35.55 533 20.98 731 28.78

8560128
DSH479X DSH184 + DSH295 903 35.55 533 20.98 731 28.78

8556259
DSH565X DSH184 + DSH381 903 35.55 533 20.98 803 31.61

8556260
DSH482 DSH240 + DSH240 1025 40.35 527 20.75 731 28.78
535
min
21.06
min
211 8.31

8556112
DSH535 DSH240 + DSH295 1025 40.35 527 20.75 731 28.78 8556112
DSH590 DSH295 + DSH295 1025 40.35 527 20.75 731 28.78 8556112
DSH620 DSH240 + DSH381 1025 40.35 527*/576** 20.75*/22.68** 803 31.61

8556115
DSH675 DSH295 + DSH381 1025 40.35 527*/576** 20.75*/22.68** 803 31.61 8556115
DSH725 DSH240 + DSH485 1025 40.35 546/563** 21.50*/22.17** 803 31.61 8556134
DSH760 DSH381 + DSH381 1025 40.35 527*/576** 20.75*/22.68** 803 31.61

8556117
DSH780 DSH295 + DSH485 1025 40.35 546*/563** 21.50*/22.17** 803 31.61
640
min
25.20
min

8556141
DSH865 DSH381 + DSH485 1025 40.35 553*/570** 21.77*/22.44** 803 31.61

8556136
DSH970 DSH485 + DSH485 1025 40.35 553*/570** 21.77*/22.44** 803 31.61 8556137
* compressor motor codes 4, 7, 9
** compressor motor code 3
Tandems to be achieved by assembly of individual compressors
Tandem assemblies
13FRCC.PC.045.A7.02
