Electrical data, connections and wiring
IP rating
The compressor terminal box according to IEC529 is IP54 for all models when correctly sized IP54 rated
cable glands are used.
First numeral, level of protection against contact and foreign objects
5 - Dust protected
Second numeral, level of protection against water
4 - Protection against water splashing
The temperature inside the terminal box
must not exceed 70°C (158°F). Consequently,
if the compressor is installed in an enclosure,
precautions must be taken to avoid that the
temperature around the compressor and
in the terminal box would rise too much.
A ventilation installation on the enclosure
panels may be necessary. If not, the electronic
protection module may not operate properly.
Any compressor damage related to this will not
be covered by Danfoss warranty. In the same
manner, cables must be selected in a way that
ensures the terminal box temperature does not
exceed 70°C (158°F).
Three phase electrical
characteristics
Terminal box temperature
Compressor model
LRA MCC Max. operating current Winding resistance
A A A Ω
Motor voltage code 3
200-230V / 3ph / 60Hz
DSH090 203 43 38 0.39
DSH105 267 51 45 0.27
DSH120 267 61 48 0.27
DSH140 304 64 56 0.24
DSH161 315 69 64 0.22
DSH184 351 75 71 0.22
DSH240 485 105 103 0.16
DSH295 560 128 112 0.13
DSH381 717 170 155 0.09
DSH485 1010 190 187 0.07
Motor voltage code 4
380-415V / 3ph / 50Hz
460V / 3ph / 60Hz
DSH090 98 22 19 1.47
DSH105 142 25 22 1.05
DSH120 142 29 24 1.05
DSH140 147 30 28 0.92
DSH161 158 35 31 0.83
DSH184 197 38.6 36 0.83
DSH240 215 51 49 0.62
DSH295 260 62 56 0.52
DSH381 320 79 72 0.42
DSH485 413 90 89 0.23
Motor voltage code 7
575V / 3ph / 60Hz
DSH090 84 18 14 2.34
DSH105 103 22 17 1.57
DSH120 103 24 19 1.57
DSH140 122 26 22 1.38
DSH161 136 29 24 1.32
DSH184 135 35 28 1.32
DSH240 175 41 38 0.94
DSH295 210 45 44 0.82
DSH381 235 60 58 0.56
DSH485 327 71 71 0.36
Motor voltage code 9
380-400V / 3ph / 60Hz
DSH090 124 26 23 1.05
DSH105 160 33 26 0.72
DSH120 160 35 29 0.72
DSH140 168 37 33 0.62
DSH161 177 41 37 0.57
DSH184 239 51 41 0.57
DSH240 260 60 58 0.42
DSH295 310 72 69 0.36
DSH381 360 90 88 0.24
DSH485 491 111 106 0.16
17FRCC.PC.045.A7.02
