Danfoss DSH090 Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONINTEGRATION INTO SYSTEMORDERING INFORMATION SYSTEM DESIGN
Manage operating envelope
R
Requirement
The operating envelopes for DSH scroll
compressors are given in the figures below and
guarantees reliable operations of the compressor
for steady-state operation.
Steady-state operation envelope is valid for a
suction superheat within 5K to 30K range at
nominal Voltage.
Operating envelope
Single DSH090 to DSH184
Tandem DSH180E to
DSH368E
Trio DSH420 to DSH552
Operating envelope
Single DSH240 to DSH485
Tandem DSH482-535, DSH590 to DSH970
Trio DSH720 to DSH1350
Condensing temperature (°C)
Condensing temperature (°F)
Evaporating temperature (°C)
Evaporating temperature (°F)
-40
5
10
15
20
25
30
35
40
45
50
55
60
65
70
41
50
59
68
77
86
95
104
113
122
131
140
149
158
-35 -30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86
S.H. = 5 K (9°F）
S.H. = 30 K（54°F）
Condensing temperature (°C)
Evaporating temperature (°C)
-40
5
10
15
20
25
30
35
40
45
50
55
60
65
70
-35 -30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
Evaporating temperature (°F)
-40 -31 -22 -13 -4 5 14 23 32 41 50 59 68 77 86
Condensing temperature (°F)
41
50
59
68
77
86
95
104
113
122
131
140
149
158
S.H. = 5 K (9°F）
S.H. = 30 K（54°F）
35FRCC.PC.045.A7.02
