Approval and certificates
DSH scroll compressors comply with the
following approvals and certificates.
Certificates are listed on:
www.commercialcompressors.danfoss.com/
documentation/certificates/
Pressure equipment
directive
Machines directive
2006/42/EC
Low voltage directive
Approval and certificates
Internal free volume
2014/68/EU
2014/35/EU
CE 0062 or CE 0038 or CE0871
(European Directive)
All DSH models
UL
(Underwriters Laboratories)
All DSH models
Other approvals / certificates Contact Danfoss
Products DSH models
Manufacturer’s declaration of incorporation Contact Danfoss
Products DSH models
Declaration of conformity Contact Danfoss
Products
Internal free volume without oil
Low pressure side High pressure side Total
litre cu.inch litre cu.inch litre cu.inch
DSH090 11.7 714 0.7 43 12.4 757
DSH105 13.6 830 0.7 43 14.3 873
DSH120 13.6 830 0.7 43 14.3 873
DSH140 13.6 830 0.7 43 14.3 873
DSH161 13.6 830 0.7 43 14.3 873
DSH184 13.9 848 0.7 43 14.6 891
DSH240 28.5 1739 2.5 153 31.0 1892
DSH295 28.5 1739 2.5 153 31.0 1892
DSH381 30.3 1849 4.0 244 34.3 2093
DSH485 28.2 1721 3.8 232 32.0 1953
Products DSH090 to 184 DSH240-295-485 DSH381
Refrigerant fluids Group 2 Group 2 Group 2
Category PED II II III
Evaluation module D1 D1 H
Maximum / Minimum temperature - Ts
-35°C < Ts < 55°C
-31°F < Ts < 131°F
-35°C < Ts < 52°C
-31°F < Ts < 125.6°F
-35°C < Ts < 52°C
-31°F < Ts < 125.6°F
Maximum allowable pressure (Low side) - Ps
33.3bar(g)
483psig
31.1bar(g)
451psig
31.1bar(g)
451psig
Declaration of conformity Contact Danfoss
20 FRCC.PC.045.A7.02
