Ordering codes
Single pack
Danfoss scroll compressors DSH can be ordered
in either industrial packs or in single packs. Please
use the code numbers from below tables for
ordering.
Compressors DSH090 to DSH184 are delivered
with flexible grommets.
For compressors DSH240 to DSH485 use in single
applications, flexible grommets are available as
accessory kit 8156138.
For use in manifold configuration, rigid spacers
are available as accessory kit 7777045 (120Z0495
for 60Hz applications).
Compressor code numbers
Compressor model Connections
Motor
protection
Code no.
3 4 7 9
200-230/3/60
380-415/3/50
460/3/60
575/3/60 380-400/3/60
DSH090 Brazed Internal 120H118 0 120H1182 120H118 4 120H118 6
DSH105 Brazed Internal 120H118 8 120H1190 120H1192 120H1194
DSH120 Brazed Internal 120H1196 120H1198 120H1200 120H1202
DSH140 Brazed Internal 120H1204 120H1206 120H1208 120H1210
DSH161 Brazed Internal 120H1212 120H1214 120H1216 120H1218
DSH184 Brazed Internal 120H1220 120H1222 120H1224 120H1226
DSH240
Brazed Module 24V AC* 120H1159 120H1119 120H1151 120H1135
Brazed Module 110-240V * 120H1161 120H1121 120H1152 120H1137
DSH295
Brazed Module 24V AC* 120H1163 120H1123 120H1153 120H1139
Brazed Module 110-240V * 120H1165 120H1125 120H1154 120H1141
DSH381
Brazed Module 24V AC* 120H1167 120H1127 120 H1155** 120H1143**
Brazed Module 110-240V * 120H1169 120H1129 120H1156** 120H1145* *
DSH485
Brazed Module 24V AC* 120H1105** 120H1131 120H1157 120H1147
Brazed Module 110-240V * - 120H1133 120H1158 120H1149
* Electronic motor protection, module located in terminal box
** Soon to be released
Mounting kit for DSH240-295-381-485 single compressor applications : Ref 8156138
56 FRCC.PC.045.A7.02
