GENERAL INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION PRODUCT INFORMATION
Model Composition
Nominal
tons 60Hz
Nominal cooling
capacity
Power
input
COP E.E.R.
Displacement
TR W Btu/h kW W/W Btu/h/W m
3
/h cu.ft/h
50Hz
Tandem
DSH180E 2xDSH090 15.0 39739 135590 13.1 3.04 10.36 30.8 1088
DSH195U DSH090 + DSH105 16.5 43237 147526 14.2 3.05 10.40 33.4 118 0
DSH210U DSH090 + DSH120 17. 5 46418 158380 15.1 3.06 10.46 35.7 1261
DSH210E 2xDSH105 18.0 46736 159462 15.3 3.06 10.43 36.0 1271
DSH230U DSH090 + DSH140 19.0 49966 170485 16.2 3.08 10.50 38.5 1360
DSH240E 2xDSH120 20.0 53098 181170 17. 2 3.08 10.53 40.6 1434
DSH251U DSH090 + DSH161 20.5 54446 185768 17.6 3.10 10.57 41.8 1476
DSH260U DSH140 + DSH120 22.0 56646 193275 18.3 3.10 10.57 43.4 1533
DSH274U DSH090 + DSH184 22.5 58558 199801 18.9 3.10 10.57 45.0 1589
DSH281U DSH161 + DSH120 23.5 61125 208558 19.6 3.11 10.62 46.7 1649
DSH280E 2xDSH140 23.5 60193 205380 19.4 3.11 10.60 46.2 1632
DSH289U DSH105 + DSH184 24.0 62056 211737 20.0 3.10 10.58 47.6 1681
DSH301U DSH161 + DSH140 25.0 64673 220663 20.7 3.12 10.65 49.5 1748
DSH304U DSH120 + DSH184 25.0 65238 222590 21.0 3.11 10.62 49.9 1762
DSH322E 2xDSH161 26.5 69152 235947 22.1 3.13 10.70 52.8 1865
DSH324U DSH140 + DSH184 27.0 68785 234695 22.1 3.12 10.64 52.7 1861
DSH345U DSH161 + DSH184 28.0 73265 249979 23.4 3.13 10.69 56.0 1978
DSH360X DSH120 + DSH240 30.0 79520 271330 25.7 3.10 10.57 59.9 2115
DSH368E 2xDSH184 30.0 77377 264011 24.7 3.13 10.68 59.2 2091
DSH424X DSH184 + DSH240 35.0 90944 310301 29.4 3.09 10.55 69.2 2444
DSH456X DSH161 +DSH295 38.0 99410 339197 31.4 3.17 10.82 74.5 2631
DSH479X DSH184 + DSH295 40.0 102628 350167 32.7 3.14 10.71 77.7 2744
DSH565X DSH184 + DSH381 45.0 1194 45 407547 38.6 3.10 10.57 89.6 3164
60Hz
DSH180E 2xDSH090 15.0 54446 185768 17.1 3.18 10.86 37. 2 1314
DSH195U DSH090 + DSH105 16.5 59212 202032 18.6 3.19 10.88 40.4 1427
DSH210U DSH090 + DSH120 17. 5 63523 216741 19.8 3.21 10.94 43.2 1526
DSH210E 2xDSH105 18.0 63979 218296 20.0 3.20 10.90 43.6 1540
DSH230U DSH090 + DSH140 19.0 68359 233242 21.3 3.21 10.95 46.5 1642
DSH240E 2xDSH120 20.0 72601 247713 22.5 3.23 11.01 49.2 1737
DSH251U DSH090 + DSH161 20.5 74018 252549 23.3 3.18 10.86 50.5 1783
DSH260U DSH140 + DSH120 22.0 77437 264214 24.0 3.23 11.01 52.5 1854
DSH274U DSH090 + DSH184 22.5 79904 272634 24.9 3.21 10.94 54.4 1921
DSH281U DSH161 + DSH120 23.5 83095 283521 26.0 3.20 10.93 56.5 1995
DSH280E 2xDSH140 23.5 82273 280715 25.5 3.23 11.01 55.8 1971
DSH289U DSH105 + DSH184 24.0 84671 288898 26.4 3.21 10.96 57.6 2034
DSH301U DSH161 + DSH140 25.0 87931 300022 27. 5 3.20 10.93 59.8 2112
DSH304U DSH120 + DSH184 25.0 88982 303606 27.6 3.22 11.0 0 60.4 2133
DSH322E 2xDSH161 26.5 93590 319329
29.4 3.18 10.86 63.8 2253
DSH324U DSH140 + DSH184 27.0 93818 320107 29.1 3.22 11.00 63.7 2250
DSH345U DSH161 + DSH184 28.0 99477 339414 31.1 3.20 10.93 67.7 2391
DSH360X DSH120 + DSH240 30.0 108390 369852 33.7 3.22 11.00 72.4 2557
DSH368E 2xDSH184 30.0 105363 359499 32.7 3.22 10.99 71.6 2529
DSH424X DSH184 + DSH240 35.0 123796 422391 38.8 3.19 10.88 83.6 2952
DSH456X DSH161 + DSH295 38.0 134830 460034 41.7 3.24 11.04 89.9 3175
DSH479X DSH184 + DSH295 40.0 139503 475984 43.3 3.22 10.99 93.8 3313
DSH565X DSH184 + DSH381 45.0 161989 552706 50.9 3.18 10.86 108.1 3818
Displacement at nominal speed: 2900rpm at 50Hz, 3500rpm at 60Hz
Net weight with oil charge
TR: Ton of Refrigeration, Standard rating conditions For 50Hz: Evaporating temperature: 5°C (41°F), Condensing temperature: 50°C (122°F), Superheat: 10K (18°F), Subcooling: 0K (0°F)
EER: Energy Efficiency Ratio Refrigerant: R410A For 60Hz: Evaporating temperature: 7.2°C (45°F), Condensing temperature: 54.4°C (130°F), Superheat: 11.1K (20°F), Subcooling: 8.3K (15°F)
COP: Coefficient Of Performance
Subject to modification without prior notification.
Data given for motor code 4 compressor with above condition, for full data details and capacity tables refer to Coolselector®2
www.coolselector.danfoss.com
50-60Hz data
Tandem compressors
Technical specifications
8 FRCC.PC.045.A7.02
