GENERAL INFORMATIONSYSTEM DESIGNINTEGRATION INTO SYSTEMORDERING INFORMATION PRODUCT INFORMATION
50-60Hz data
Tandem and trios
Technical specifications
Model Composition
Nominal
tons 60Hz
Nominal cooling
capacity
Power
input
COP E.E.R.
Displacement
TR W Btu/h kW W/W Btu/h/W m
3
/h cu.ft/h
50Hz
Tandem
DSH482 2xDSH240 40.0 104511 356602 34.1 3.07 10.46 79.2 2797
DSH535 DSH240 + DSH295 45.0 116195 396468 37.4 3.11 10.60 87.7 3097
DSH590 2xDSH295 50.0 127879 436335 40.7 3.14 10.72 96.2 3397
DSH620 DSH240 + DSH381 50.0 133012 453850 43.3 3.08 10.49 99.6 3517
DSH675 DSH295 + DSH381 55.0 144696 493717 46.6 3.11 10.60 108.1 3818
DSH725 DSH240 + DSH485 60.0 154824 528275 49.8 3.11 10.62 116.6 4118
DSH760 2xDSH381 60.0 161513 551099 52.4 3.08 10.51 120 4238
DSH780 DSH295 + DSH485 65.0 166508 568141 53.1 3.14 10.71 125.1 4418
DSH865 DSH381 + DSH485 70.0 183325 625524 58.9 3.11 10.61 137 4838
DSH970 2xDSH485 80.0 205137 699948 65.4 3.13 10.70 154 5438
Trio
DSH420 3xDSH140 35.0 89106 304028 29.1 3.07 10.46 69.3 2447
DSH483 3xDSH161 39.0 102367 349277 33.1 3.09 10.56 79.2 2797
DSH552 3xDSH184 44.0 114543 390822 37.1 3.09 10.54 88.8 3136
DSH720 3xDSH240 60.0 154710 527885 51.1 3.03 10.33 118.8 4195
DSH885 3xDSH295 75.0 189302 645916 61.1 3.10 10.58 144.3 5096
DSH1140 3xDSH381 90.0 239092 815805 78.6 3.04 10.38 180 6357
DSH1245 2xDSH381 + DSH485 100.0 260617 889253 85.1 3.06 10.44 197 6957
DSH1350 DSH381 + 2xDSH485 110.0 282143 962701 91.7 3.08 10.50 214 7557
DSH1455 3xDSH485 120.0 303669 1036149 98.2 3.09 10.56 231 8158
60Hz
Tandem
DSH482 2xDSH240 40.0 142228 485297 44.9 3.17 10.80 95.6 3376
DSH535 DSH240 + DSH295 45.0 157936 538892 49.4 3.20 10.90 105.8 3736
DSH590 2xDSH295 50.0 173643 592487 53.9 3.22 10.99 116 4097
DSH620 DSH240 + DSH381 50.0 180421 615616 57.0 3.17 10.80 120.1 4241
DSH675 DSH295 + DSH381 55.0 196129 669211 61.5 3.19 10.89 130.3 4602
DSH725 DSH240 + DSH485 60.0 211737 722468 66.1 3.20 10.93 140.7 4969
DSH760 2xDSH381 60.0 218615 745935 69.0 3.17 10.80 144.6 5107
DSH780 DSH295 + DSH485 65.0 227444 776063 70.6 3.22 10.99 150.9 5329
DSH865 DSH381 + DSH485 70.0 249930 852787 78.2 3.20 10.91 165.2 5834
DSH970 2xDSH485 80.0 281246 959639 87.3 3.22 10.99 185.8 6561
Trio
DSH420 3xDSH140 35.0 121790 415549 38.3 3.18 10.86 83.7 2956
DSH483 3xDSH161 39.0 138543 472710 44.1 3.14 10.72 95.7 3380
DSH552 3xDSH184 44.0 155971 532175 49.1 3.18 10.84 107.4 3793
DSH720 3xDSH240 60.0 210544 718397 67.4 3.12 10.66 143.4 5064
DSH885 3xDSH295 75.0 257048 877073 80.9 3.18 10.84 174 6145
DSH1140 3xDSH381 90.0 323620 1104224 103.6 3.12 10.66 216.9 7660
DSH1245 2xDSH381 + DSH485 100.0 354525 1209675 112.7 3.15 10.73 237. 5 8387
DSH1350 DSH381 + 2xDSH485 110.0 385430 1315125 121.8 3.16 10.79 258.1 9115
DSH1455 3xDSH485
120.0 416335 1420575 131.0 3.18 10.85 278.7 9842
Displacement at nominal speed: 2900rpm at 50Hz, 3500rpm at 60Hz
Net weight with oil charge
TR: Ton of Refrigeration, Standard rating conditions For 50Hz: Evaporating temperature: 5°C (41°F), Condensing temperature: 50°C (122°F), Superheat: 10K (18°F), Subcooling: 0K (0°F)
EER: Energy Efficiency Ratio Refrigerant: R410A For 60Hz: Evaporating temperature: 7.2°C (45°F), Condensing temperature: 54.4°C (130°F), Superheat: 11.1K (20°F), Subcooling: 8.3K (15°F)
COP: Coefficient Of Performance
Subject to modification without prior notification.
Data given for motor code 4 compressor with above condition, for full data details and capacity tables refer to Coolselector®2
www.coolselector.danfoss.com
9FRCC.PC.045.A7.02
