Danfoss DSH090 Application Guidelines

GENERAL INFORMATIONPRODUCT INFORMATIONINTEGRATION INTO SYSTEMORDERING INFORMATION SYSTEM DESIGN
Models Composition
Refrigerant charge limit
kg lbs
Single
DSH090 8 18
DSH105 10 22
DSH120 10 22
DSH140 10 22
DSH161 10 22
DSH184 10 22
DSH240 15 33
DSH295 15 33
DSH381 17 37
DSH485 17 37
Tandem
DSH180E 2×DSH090 12 26
DSH195U DSH090 + DSH105 12 26
DSH210U DSH090 + DSH120 12 26
DSH210E 2×DSH105 12 26
DSH230U DSH090 + DSH140 12 26
DSH240E 2×DSH120 12 26
DSH251U DSH090 + DSH161 12 26
DSH260U DSH140 + DSH120 12 26
DSH274U DSH090 + DSH184 12 26
DSH281U DSH161 + DSH120 12 26
DSH280E 2×DSH140 14 31
DSH289U DSH105 + DSH184 12 26
DSH301U DSH161 + DSH140 14 31
DSH304U DSH120 + DSH184 12 26
DSH322E 2×DSH161 14 31
DSH324U DSH140 + DSH184 14 31
DSH345U DSH161 + DSH184 14 31
DSH368E 2×DSH184 14 31
DSH360X DSH120 + DSH240 14 31
DSH424X DSH184 + DSH240 14 31
DSH456X DSH161 + DSH295 14 31
DSH479X DSH184 + DSH295 14 31
DSH565X DSH184 + DSH381 14 31
DSH482 2xDSH240 21 46
DSH535 DSH240 + DSH295 21 46
DSH590 2xDSH295 25 55
DSH620 DSH240 + DSH381 21 46
DSH675 DSH295 + DSH381 25 55
DSH760 2xDSH381 29 64
DSH725 DSH240 + DSH485 21 46
DSH780 DSH295 + DSH485 25 55
DSH865 DSH381 + DSH485 29 64
DSH970 2xDSH485 34 75
Trio
DSH420 3xDSH140 14 31
DSH483 3xDSH161 14 31
DSH552 3xDSH184 14 31
DSH720 3xDSH240 21 46
DSH885 3xDSH295 25 55
DSH1140 3xDSH381 29 64
DSH1245 2xDSH381 + DSH485 29 64
DSH1350 DSH381 + 2xDSH485 29 64
DSH1455 3xDSH485 34 75
Manage off cycle migration
Charge limits are defined in the table below :
***Pump-down cycle
By decreasing pressure in the sump, pump down
system:
• evacuates refrigerant from oil
• set the sump saturating pressure much
lower than ambiance temperature and due
to that, avoid refrigerant condensation in the
compressor.
Pump-down must be set higher than 1.7bar(g)
(25 psig).
For more details on pump-down cycle see
section “Control Logic”.
**** External non-return valve is only for
DSH090-105-120-140-161-184.
DSH240-295-381-485 have integrated internal
non-return valve
42 FRCC.PC.045.A7.02
