Danfoss Eco Installation Guide

26
06/2015 VIJPD102 Danfoss Heating Solutions
User Guide eco Intelligent Radiator Thermostat
5.6 Limiting the temperature setting range
1. 2.
If the display is off, press , then press both
to open thefuntction menu. Press
again to open theadvance menu.Use to
select MAX/MIN, press to conrm.
Use to set MAX temperature, press to
confirm.
Use to set MIN temperature, press to
confirm.
5.7 Child Lock
Protect your eco settings from tampering by activating the Child Lock.
1. 2.
If the display is off, press , then press both
to open thefuntction menu. Press
again to open theadvance menu. Use to
select , press to conrm.
is shown on the Home Screen, indicating
Child Lock is on.
Deactivate Child Lock by pressing all three
buttons simultaneously for 5 seconds.
5.8 Pause Function
1. 2
To Pause the system, press , to activate the
display. Press twice, this now sets eco into
Pause. The display will flash slowly to indicate
that Pause is activated.
To disable the Pause, press to activate the
display, then twice, to disable Pause.

Danfoss Eco Specifications

General

Package weight	250 g
Accuracy	50 sec/month
Noise level	30 dB
Certification	CE, ERC, EAC
Product color	White
Smart thermostat	-
Spindle movement	2 - 4.5 mm
Operating frequency	2400 MHz
Wireless connection	Yes
Maximum water temperature	90 °C
Storage temperature (T-T)	-20 - 65 °C
Temperature control range	4 - 28 °C
Operating temperature (T-T)	0 - 40 °C
International Protection (IP) code	IP20
Display type	LCD
Battery type	AA
Battery voltage	1.5 V
Power consumption (typical)	1.2 W
Number of batteries supported	2

Weight and Dimensions

Weight	100 g
