Danfoss Eco Installation Guide

10
06/2015 VIJPD102 Danfoss Heating Solutions
1.11 Resetting eco to default settings
1. 2.
Remove the battery cover and take out one
battery.
Press and hold , Keep holding while rein-
serting the battery. The screen will show all
functions then return to a large flashing M.
1.12 Removing an adapter from eco
1. 2.
Remove the battery cover. Insert a small Allen key or similar into the lock-
ing hole to lock the adapter ring.
3. 4.
With the Allen key locking the adapter ring,
turn the adapter in the shown direction.
Put back the battery cover.
Mount eco on another valve adapter accord-
ing to the instructions supplied with the
adapter.
Installation Guide eco Intelligent Radiator Thermostat

Danfoss Eco Specifications

General

Package weight	250 g
Accuracy	50 sec/month
Noise level	30 dB
Certification	CE, ERC, EAC
Product color	White
Smart thermostat	-
Spindle movement	2 - 4.5 mm
Operating frequency	2400 MHz
Wireless connection	Yes
Maximum water temperature	90 °C
Storage temperature (T-T)	-20 - 65 °C
Temperature control range	4 - 28 °C
Operating temperature (T-T)	0 - 40 °C
International Protection (IP) code	IP20
Display type	LCD
Battery type	AA
Battery voltage	1.5 V
Power consumption (typical)	1.2 W
Number of batteries supported	2

Weight and Dimensions

Weight	100 g
