The brackets are identical, each with 6 mounting holes.
Figure 8: Installing the Back-channel Cooling Option Brackets
1 The brackets 2 The top hood
4. Attach a duct against the top hood to direct the airflow.
5. Adjust the air guide at the bottom.
Figure 9: Back-channel Cooling Option Air Guide at the Bottom
10 | Danfoss Drives Oy © 2024.09 AN484843731544en-000101 / 172K4825A
Installation Guide | iC7-Automation Air-cooled Enclosed Drives Mechanical Installation
