Danfoss iC7 - Motor Cable Size Recommendations, UL 480

Table 14: Mains Cable Size Recommendations, UL 480 V (continued)
Model code Frame I
N
[A] Mains cable
[AWG]
Cable
termination,
Panduit
terminal part
number
Maximum
cable size
Maximum
number of
mains cables
(1)
(hole size of
the mains
terminal
[mm])
Number of
grounding
holes on PE
busbar (hole
size [mm])
iC7-60EA3A05-
1260
955 6 x 4/0 LCAX4/0-12-X 500MCM 8 (Ø10.5) 8 (Ø10.5)
iC7-60EA3A05-
1450
1106 6 x 300 MCM LCAX300-12-6 500MCM 8 (Ø10.5) 8 (Ø10.5)
iC7-60EA3A05-
1710
2xAE11 +
2xIE11
1306 6 x 350 MCM LCAX350-12-6 500MCM 8 (Ø10.5) 8 (Ø10.5)
1) Cable lugs installed on both sides of the fixing hole
6.2.5 Motor Cable Size Recommendations, UL 480 V
Table 15: Motor Cable Size Recommendations, UL 480 V
Model code Frame I
N
[A] Motor cable
[AWG]
Cable
termination,
Panduit
terminal part
number
Maximum
cable size
Maximum
number of
motor cables
(bolt size)
Number of
grounding
holes on PE
busbar (hole
size [mm])
(1)
iC7-60EA3N05-
206A
206 2 x 1/0 LCAX300-12-6 300MCM 2 (M10) 2 (Ø10.5)
iC7-60EA3N05-
245A
245 2 x 2/0 LCAX300-12-6 300MCM 2 (M10) 2 (Ø10.5)
iC7-60EA3N05-
302A
302 2 x 4/0 LCAX300-12-6 300MCM 2 (M10) 2 (Ø10.5)
iC7-60EA3N05-
385A
FE9
385 2 x 300 MCM LCAX300-12-6 300MCM 2 (M10) 2 (Ø10.5)
iC7-60EA3N05-
480A
480 3 x 4/0 LCAX300-12-6 300MCM 3 (M10) 4 (Ø10.5)
iC7-60EA3N05-
588A
FE10
588 3 x 300 MCM LCAX300-12-6 300MCM 3 (M10) 4 (Ø10.5)
iC7-60EA3A05-
385A
372 2 x 300 MCM LCAX300-12-6 500MCM 4 (M10) 4 (Ø10.5)
iC7-60EA3A05-
480A
466 3 x 4/0 LCAX4/0-12-X 500MCM 4 (M10) 4 (Ø10.5)
iC7-60EA3A05-
590A
AE10 + IE10
531 3 x 250 MCM LCAX250-12-X 500MCM 4 (M10) 4 (Ø10.5)
