6.3.2 AC Fuses, 380–500 V AC
Table 17: AC Fuses, 380–500 V AC
Model code Frame Rated
current I
L
[A]
Number
of fuses
Fuse size Part number Fuse U
n
[V]
Fuse I
n
[A]
I
cp,mr
[A]
(1)
iC7-60EA3N05-206A 206 3 00 170M2619
(2)
700 315 2000
iC7-60EA3N05-245A 245 3 00 170M2620
(2)
700 350 2400
iC7-60EA3N05-302A 302 3 00 170M2621
(2)
700 400 2800
iC7-60EA3N05-385A
FE9
385 3 00 170M9007
(2)
550 475 3700
iC7-60EA3N05-480A 480 3 1 170M4016
(2)
700 630 4500
iC7-60EA3N05-588A
FE10
588 3 1 170M4017
(2)
700 700 5400
iC7-60EA3A05-385A 385 3 33 PC33UD69V550
TF
(3)
690 550 3288
iC7-60EA3A05-480A 480 3 33 PC33UD69V700
TF
(3)
690 700 4822
iC7-60EA3A05-590A
AE10 +
IE10
590 3 33 PC33UD69V700
TF
(3)
690 700 4822
iC7-60EA3A05-658A 658 6
(4)
33 PC33UD69V550
TF
(3)
690 550 6576
iC7-60EA3A05-730A 730 6
(4)
33 PC33UD69V550
TF
(3)
690 550 6576
iC7-60EA3A05-820A 820 6
(4)
33 PC33UD69V550
TF
(3)
690 550 6576
iC7-60EA3A05-880A
AE11 +
IE11
880 6
(4)
33 PC33UD69V550
TF
(3)
690 550 6576
iC7-60EA3A05-1000 1000 6 33 PC33UD69V700
TF
(3)
690 700 –
iC7-60EA3A05-1100
2xAE10 +
2xIE10
1100 6 33 PC33UD69V700
TF
(3)
690 700 –
iC7-60EA3A05-1260 1260 12
(4)
33 PC33UD69V550
TF
(3)
690 550 –
iC7-60EA3A05-1450 1450 12
(4)
33 PC33UD69V550
TF
(3)
690 550 –
iC7-60EA3A05-1710
2xAE11 +
2xIE11
1707 12
(4)
33 PC33UD69V550
TF
(3)
690 550 –
1) Current, prospective, minimum rating
2) Bussmann
3) Mersen
4) Double fuse per phase
