Table 5: I/O and Relay Option Signals
Terminal Function Connector type
X13 I/O terminal 2 x 11 spring force connector 0.2–1.5mm
2
X51 Thermistor input 1 x 2 spring force connector 0.25–2.5mm
2
X101 Relay 1 1 x 3 spring force connector 0.25–2.5mm
2
X102 Relay 2 1 x 3 spring force connector 0.25–2.5mm
2
X103 Relay 3 1 x 2 spring force connector 0.25–2.5mm
2
Table 6: I/O Terminal Signals (X13)
Terminal Function Terminal block Description
11 +24 V
out
XD2.1:11
12 +24 V
out
XD2.1:12
Control voltage output.
24V DC (-15...+20%)
Maximum current 200mA
Short-circuit protected
13 DI 1 XD2.1:13
14 DI 2 XD2.1:14
15 DI 3 XD2.1:15
16 DI 4 XD2.1:16
17 DI 5 XD2.1:17
18 DI 6 XD2.1:18
Configurable digital input, galvanically isolated.
24V DC, 0 < 5V, 1 > 15V.
Input load 7.5mA constant current + 10kΩ resistive load, maximum pulse
frequency 100kHz.
19 DGND XD2.1:19
20 DGND XD2.1:20
Digital input ground, not isolated by default.
When using the internal +24V
out
supply, connect the external jump wire be-
tween DGND and GND.
When using the external +24V DC supply, remove the external jump wire be-
tween DGND and GND.
21 DO 1 XD2.1:21
22 DO 2 XD2.1:22
Configurable digital output.
(1)
Push-pull 24V/50mA
Open collector (NPN/PNP) 48V/50mA
Short-circuit protected
23 GND XD2.1:23
24 GND XD2.1:24
I/O ground.
Ground for digital outputs, +10V Ref, +24V
out
, analog inputs, and analog
outputs.
