Danfoss Metasys N2 Operating Instructions

Mains Supply 3x525-690 V AC
P710 P800 P900 P1M0 P1M2 P1M4
Typical Shaft output at 550 V [kW] 560 670 750 850 1000 1100
Typical Shaft output at 575 V [HP] 750 950 1050 1150 1350 1550
Typical Shaft output at 690 V [kW] 710 800 900 1000 1200 1400
Enclosure IP21, 54 without/with
options cabinet
F1/ F3 F1/ F3 F1/ F3 F2/F4 F2/ F4 F2/F4
Output current
Continuous
(at 550 V) [A]
763 889 988 1108 1317 1479
Intermittent (60 s overload, at 550
V) [A]
839 978 1087 1219 1449 1627
Continuous
(at 575/ 690 V) [A]
730 850 945 1060 1260 1415
Intermittent (60 s overload, at
575/690 V) [A]
803 935 1040 1166 1386 1557
Continuous KVA
(at 550 V) [KVA]
727 847 941 1056 1255 1409
Continuous KVA
(at 575 V) [KVA]
727 847 941 1056 1255 1409
Continuous KVA
(at 690 V) [KVA]
872 1016 1129 1267 1506 1691
Max. input current
Continuous
(at 550 V ) [A]
743 866 962 1079 1282 1440
Continuous
(at 575 V) [A]
711 828 920 1032 1227 1378
Continuous
(at 690 V) [A]
711 828 920 1032 1227 1378
Max. cable size,motor [mm
2
(AWG
2)
)]
8x150 (8x300 mcm) 12x150 (12x300 mcm)
Max. cable size,mains F1/F2 [mm
2
(AWG
2)
)]
8x240 (8x500 mcm)
Max. cable size,mains F3/F4 [mm
2
(AWG
2)
)]
8x456 (8x900 mcm)
Max. cable size, loadsharing [mm
2
(AWG
2)
)]
4x120 (4x250 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
4x185 (4x350 mcm) 6x185 (6x350 mcm)
Max. external pre-fuses [A]
1)
1600 2000 2500
Est. power loss at rated max. load
[W]
4)
, 600 V, F1 & F2
10771 12272 13835 15592 18281 20825
Est. power loss at rated max. load
[W]
4)
, 690 V, F1 & F2
11315 12903 14533 16375 19207 21857
Max added losses of Circuit Breaker
or Disconnect & Contactor, F3 & F4
427 532 615 665 863 1044
Max Panel Options Losses 400
Weight,enclosure IP21, IP 54 [kg] 1004/1299 1004/1299 1004/1299 1246/1541 1246/1541 1280/1575
Weight, Rectifier Module [kg] 102 102 102 136 136 136
Weight, Inverter Module [kg] 102 102 136 102 102 136
Efficiency
4)
0.98
Output frequency 0-500 Hz
Heat sink overtemp. trip
95 °C
Power card amb. trip
68 °C
Table 7.8
General Specifications
VLT HVAC Drive FC 102 Operating Instructions
MG11F402 - Rev. 2013-12-16 127
