1) For type of fuse see section Fuses.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within +/-15% (tolerence relates to
variety in voltage and cable conditions). Values are based on a typical motor efficiency (eff2/eff3 border line).
Motors with lower efficiency also adds to the power loss in the frequency converter and opposite. If the switching
frequency is increased comed to the default setting, the power losses may rise significantly. LCP and typical
control card power consumptions are included. Further options and customer load may add up to 30 W to the
losses. (Though typical only 4 W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be
allowed for (+/-5%).
General Specifications VLT HVAC Drive FC 102 Operating Instructions
128 MG11F402 - Rev. 2013-12-16
