Danfoss PVED-CLS User Manual

152 | © Danfoss | August 2018 AQ00000211
ENGINEERING TOMORROW
17.4.5 Analog Sensor Calibration Data
Name
Address
Data type
Unit
Description of parameter
User
Range
Danfoss default value
Safety critical parameters ‘S’
Min.
Max.
Primary analogue sensor
max left position
P3205 U16 mVolts Primary analogue sensor voltage output for leftmost position OEM, Dealer 0 6000 500
Primary analogue sensor
max right position
P3207 U16 mVolts Primary analogue sensor voltage output for rightmost position OEM, Dealer 0 6000 4500
Primary analogue sensor
neutral position
P3209 U16 mVolts Primary analogue sensor voltage output for neutral position OEM, Dealer 0 6000 2500
Redundant analogue sensor
max left position
P3211 U16 mVolts Redundant analogue sensor voltage output for leftmost position OEM, Dealer 0 6000 500
Redundant analogue sensor
max right position
P3213 U16 mVolts Redundant analogue sensor voltage output for rightmost position OEM, Dealer 0 6000 4500
Redundant analogue sensor
neutral position
P3215 U16 mVolts Redundant analogue sensor voltage output for neutral position OEM, Dealer 0 6000 2500
5V sensor supply for
primary analogue sensor
during calibration
P3217 U16 mVolts Measured Supply voltage during calibration of the primary analogue sensor OEM, Dealer 4650 5350 5000
5V sensor supply for
redundant analogue sensor
during calibration
P3219 U16 mVolts
Measured Supply voltage during calibration of the redundant analogue
sensor
OEM, Dealer 4650 5350 5000
Automatically adjusted
cylinder stroke volume
(analogue WAS)
P3221 U16 ccm
Automatically adjusted cylinder stroke volume, for using analogue WAS,
found during WAS auto-calibration
OEM, Dealer 100 65535 65535
Automatically adjusted
maximum steer angle to
left side (analogue WAS)
P3223 U16 Deg
Automatically adjusted maximum steer angle to left side, for using
analogue WAS, found during WAS auto-calibration
OEM, Dealer 0 65535 65535
Automatically adjusted
maximum steer angle to
right side (analogue WAS)
P3225 U16 Deg
Automatically adjusted maximum steer angle to right side, for using
analogue WAS, found during WAS auto-calibration
OEM, Dealer 0 65535 65535
Table 68
Important
For analog sensor calibration data sector, the following rules apply:
P3205 < P3207 < P3209 OR P3205 > P3207 > P3209
AND if P3245 is set to 255 (redundant WAS is present)
P3211 < P3213 < P3215 OR P3211 > P3213 > P3215
