11.3 OPEN LOOP FILTER
As a risk mitigation method, Danfoss wants to avoid unintended spool actuation, etc. when driving on bumpy-ground,
therefore an open loop joystick and open loop mini-steering wheel signal filter has been applied to the PVED-CLS’s
steering wheel control algorithm.
Practically, if open loop mini-steering wheel has been selected as steering type, any mini-steering wheel signals, i.e. where
the steering angle velocity is below the value in P3649, will be disregarded.
Furthermore, if open loop joystick steering type has been selected, any joystick flow commands below the value in P3648
will be disregarded.
Name
Address
Data type
Unit
Description of parameter
User
Range
Danfoss
default
value
Safety critical parameters ‘S’
Min.
Max.
AUX – Joystick no-
activation threshold
P3648 U8 IR
Min Flow command from AUX joystick below which the flow command
of 0 is used by the AUX control algorithm
OEM 0 100 5
AUX - Mini-steering
no-activation threshold
P3649 U8 dRpm
Min AUX steering angle velocity value below which the angle velocity of
0 is used by the AUX control algorithm
OEM 0 100 5
Table 42 (b)
