Danfoss PVED-CLS User Manual

© Danfoss | August 2018 AQ00000211 | 77
ENGINEERING TOMORROW
Name
Address
Data type
Unit
Description of parameter
User
Range
Danfoss default value
Safety critical parameters ‘S’
Min.
Max.
Primary analogue sensor
max left position
P3205 U16 mVolts Primary analogue sensor voltage output for leftmost position OEM, Dealer 0 6000 500
Primary analogue sensor
max right position
P3207 U16 mVolts Primary analogue sensor voltage output for rightmost position OEM, Dealer 0 6000 4500
Primary analogue sensor
neutral position
P3209 U16 mVolts Primary analogue sensor voltage output for neutral position OEM, Dealer 0 6000 2500
Redundant analogue
sensor max left position
P3211 U16 mVolts Redundant analogue sensor voltage output for leftmost position OEM, Dealer 0 6000 500
Redundant analogue
sensor max right
position
P3213 U16 mVolts Redundant analogue sensor voltage output for rightmost position OEM, Dealer 0 6000 4500
Redundant analogue
sensor neutral position
P3215 U16 mVolts Redundant analogue sensor voltage output for neutral position OEM, Dealer 0 6000 2500
5V sensor supply for
primary analogue sensor
during calibration
P3217 U16 mVolts Measured Supply voltage during calibration of the primary analogue sensor OEM, Dealer 4650 5350 5000
5V sensor supply for
redundant analogue
sensor during calibration
P3219 U16 mVolts
Measured Supply voltage during calibration of the redundant analogue
sensor
OEM, Dealer 4650 5350 5000
Table 33
Important
If WAS interface is selected as Analogue then joystick calibration cannot be performed.
Figure 35
