A2 A3 A5 B1 B2 B3 B4 C1 C2 C3 C4
IP20/21 IP20/21 IP55/66 IP21/55/66 IP21/55/66 IP20 IP20 IP21/55/66 IP21/55/66 IP20 IP20
Accessory bags containing necessary brackets, screws and connectors are included with the drives upon delivery. Top and bottom mounting holes. (C3+C4 only)
All measurements in mm.
* A5 in IP55/66 only!
4.2.1. Mechanical Front Views
4. Mechanical installation
