[23] Set-up select bit 0
[24] Set-up select bit 1
[30] Counter input
[32] Pulse input
[34] Ramp bit 0
[36] Mains failure inverse
[37] Fire Mode
[52] Run permissive
[53] Hand start
[54] Auto start
[55] DigiPot increase
[56] DigiPot decrease
[57] DigiPot clear
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[66] Sleep Mode
[78] Reset Maint. Word
[120] Lead Pump Start
[121] Lead Pump Alternation
[130] Pump 1 Interlock
[131] Pump 2 Interlock
[132] Pump 3 Interlock
5-30 Terminal 27 Digital Output
Option: Function:
[0] * No operation Same options and functions as par. 5-3*.
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Standby / no warning
[5] Running
[6] Running / no warning
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
8. How to programme the frequency converter
VLT
®
AQUA Drive
Operating Instructions
86
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark
8
