6-25 Terminal 54 High Ref./Feedb. Value
Range: Function:
100.000 N/
A*
[-999999.999 - 999999.999 N/A] Enter the analog input scaling value that corresponds to the high voltage/high current value set in
par. 6-21
Terminal 54 High Voltage
and par. 6-23 Terminal
54 High Current
.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output.
[0] * No operation
[100] Output freq. 0-100 : 0 - 100 Hz
[101] Reference Min-Max : Minimum reference - Maximum reference
[102] Feedback +-200% : -200% to +200% of par. 2-14
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (par. 16-37)
[104] Torque 0-Tlim : 0 - Torque limit (par. 4-16)
[105] Torque 0-Tnom : 0 - Motor rated torque
[106] Power 0-Pnom : 0 - Motor rated power
[107] Speed 0-HighLim : 0 - Speed High Limit (par. 4-13 and par. 4-14)
[113] Ext. Closed Loop 1 0 - 100%
[114] Ext. Closed Loop 2 0 - 100%
[115] Ext. Closed Loop 3 0 - 100%
[130] Out frq 0-100 4-20mA :0 - 100 Hz
[131] Reference 4-20mA Minimum Reference - Maximum Reference
[132] Feedback 4-20mA -200% to +200% of par. 2-14
[133] Motor cur. 4-20mA 0 - Inverter Max. Current (par. 16-37 Inv.
Max. Current
)
[134] Torq.0-lim 4-20 mA :0 - Torque limit (par. 4-16)
[135] Torq.0-nom 4-20mA :0 - Motor rated torque
[136] Power 4-20mA 0 - Motor rated power
[137] Speed 4-20mA 0 - Speed High Limit (par. 4-13 and par. 4-14)
[139] Bus ctrl. 0 - 100%
[140] Bus ctrl. 4-20 mA 0 - 100%
[141] Bus ctrl t.o. 0 - 100%
[142] Bus ctrl t.o. 4-20mA 0 - 100%
[143] Ext. CL 1 4-20mA 0 - 100%
[144] Ext. CL 2 4-20mA 0 - 100%
[145] Ext. CL 3 4-20mA 0 - 100%
NB!
Values for setting the Minimum Reference is found in par. 3-02
Minimum Reference
and par. 20-13 Minimum
Reference/Feedb.
- values for Maximum
Reference is found in par. 3-03
Maximum Reference
and par. 20-14 Maximum
Reference/Feedb.
.
