6-22 Terminal 54 Low Current
Range: Function:
4 mA
*
[0.0 to par. 6-23 mA] Enter the low current value. This reference signal should corre-
spond to the low reference/feedback value, set in par. 6-24. The
value must be set at >2 mA in order to activate the Live Zero
Time-out Function in par. 6-01.
6-23 Terminal 54 High Current
Range: Function:
20.0
mA
*
[Par. 6-22 to - 20.0
mA]
Enter the high current value corresponding to the high refer-
ence/feedback value set in par. 6-25.
6-24 Terminal 54 Low Ref./Feedb. Value
Range: Function:
0.000
Unit
*
[-1000000.000 to par.
6-25]
Enter the analog input scaling value that corresponds to the low
voltage/low current value set in par. 6-20/6-22.
6-25 Terminal 54 high ref./feedb. value
Range: Function:
100.000
Unit
*
[Par. 6-24 to
1000000.000]
Enter the analog input scaling value that corresponds to the high
voltage/high current value set in par. 6-21/6-23.
6-26 Terminal 54 Filter Time Constant
Range: Function:
0.001s
*
[0.001 - 10.000 s] Enter the time constant. This is a first-order digital low pass filter
time constant for suppressing electrical noise in terminal 54. A
high time constant value improves dampening but also increa-
ses the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
6-27 Terminal 54 Live Zero
Option: Function:
This parameter makes it possible to disable the Live Zero mon-
itoring. E.g. to be used if the analog outputs are used as part of
a decentral I/O system (e.g. when not part of any frequency
converter related control functions, but feeding an external con-
trol system with data)
[0] Disabled
[1]
*
Enabled
2.8.6. 6-3* Analog Input 3 (MCB 101)
Parameter group for configuring the scale and limits for analog input 3 (X30/11) placed on option
module MCB 101.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
100
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
