0-82 Additional Working Days
Array with 5 elements [0]-[4] displayed below parameter number in display. Press OK and
Step between elements by means of and buttons on the LCP.
0
*
[0-4] Defines dates for additional working days that normally would
be non-working days according to par. 0-81
Working Days
.
0-83 Additional Non-Working Days
Array with 15 elements [0]-[14] displayed below parameter number in display. Press OK and
Step between elements by means of and buttons on the LCP.
0
*
[0-14] Defines dates for additional non-working days that normally
would be working days according to par. 0-81
Working Days
.
0-89 Date and Time Readout
Option: Function:
Displays the current date and time. The date and time is upda-
ted continuously.
The clock will not begin counting until a setting different from
default has been made in par. 0-70.
2.3. Main Menu - Load and Motor - Group 1
2.3.1. General Settings, 1-0*
Define whether the frequency converter operates in open loop or closed loop.
1-00 Configuration Mode
Option: Function:
[0]
*
Open loop Motor speed is determined by applying a speed reference or by
setting desired speed when in Hand Mode.
Open Loop is also used if the frequency converter is part of a
closed loop control system based on an external PID controller
providing a speed reference signal as output.
[3] Closed loop Motor Speed will be determined by a reference from the built-
in PID controller varying the motor speed as part of a closed
loop control process (e.g. constant pressure or flow). The PID
controller must be configured in par. 20-**, Drive Closed Loop
or via the Function Setups accessed by pressing the [Quick Me-
nus] button.
This parameter can not be changed when motor is running.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
44
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
