Danfoss vlt aqua Programming Guide

15-99 Parameter Metadata
Array [23]
0 *
[0 - 9999] This parameter contains data used by the MCT10 software tool.
2.15. Main Menu - Data Readouts - Group 16
2.15.1. 16-** Data Readouts
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and
status words.
2.15.2. 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word,
status.
16-00 Control Word
Range: Function:
0
*
[0 - FFFF] View the Control word sent from the frequency converter via the
serial communication port in hex code.
16-01 Reference [Unit]
Range: Function:
0.000
*
[-999999.000 -
999999.000]
View the present reference value applied on impulse or analog
basis in the unit resulting from the configuration selected in par.
1-00 (Hz, Nm or RPM).
16-02 -200.0 - 200.0 %
Range: Function:
0.0%
*
[] View the total reference. The total reference is the sum of dig-
ital, analog, preset, bus, and freeze references, plus catch-up
and slow-down.
16-03 Status Word
Range: Function:
0
*
[0 - FFFF] View the Status word sent from the frequency converter via the
serial communication port in hex code.
16-05 Main Actual Value [%]
Range: Function:
0.00%
*
[-100.00% -
100.00%]
View the two-byte word sent with the Status word to the bus
Master reporting the Main Actual Value. Please refer to the Pro-
fibus Operating Instructions MG.33.CX.YY for a detailed de-
scription.
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 161
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
