Danfoss vlt aqua Programming Guide

[3-02] Minimum Reference
[3-03] Maximum Reference
[3-41] Ramp 1 Ramp Up
Time
[3-42] Ramp 1 Ramp Down
Time
[3-51] Ramp 2 Ramp Up
Time
[3-52] Ramp 2 Ramp Down
Time
[3-80] Jog Ramp Time
[3-81] Quick Stop Ramp
Time
[4-11] Motor Speed Low
Limit [RPM]
[4-13] Motor Speed High
Limit [RPM]
[4-16] Torque Limit Motor
Mode
[4-17] Torque Limit Genera-
tor Mode
[5-90 ] Digital & Relay Bus
Control
[5-93] Pulse Out #27 Bus
Control
[5-95] Pulse Out #29 Bus
Control
[6-53] Terminal 42 Output
Bus Control
[7-28] Minimum Feedback
[7-29] Maximum Feedback
[8-90] Bus Jog 1 Speed
[8-91] Bus Jog 2 Speed
[16-80] Fieldbus CTW 1
[16-82] Fieldbus REF 1
9-16 PCD Read Configuration
Array [10]
Select the parameters to be assigned to PCD 3 to 10 of the tele-
grams. The number of available PCDs depends on the telegram
type. PCDs 3 to 10 contain the actual data values of the selected
parameters. For standard Profibus telegrams, see par. 9-22.
None
[16-00] Control Word
[16-01] Reference [Unit]
[16-02] Reference %
2. Parameter Description VLT
®
AQUA Drive Programming Guide
116 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
