Danfoss vlt aqua Programming Guide

[16-03] Status Word
[16-05] Main Actual Value [%]
[16-09] Custom Readout
[16-10] Power [kW]
[16-11] Power [hp]
[16-12] Motor Voltage
[16-13] Frequency
[16-14] Motor Current
[16-15] Frequency [%]
[16-16] Torque
[16-17] Speed [RPM]
[16-18] Thermal Motor Load
[16-22] Torque [%]
[16-30] DC Link Voltage
[16-32] Brake Energy / s
[16-33] Brake Energy / 2 min
[16-34] Heatsink Temp.
[16-35] Thermal Drive Load
[16-38] SL Controller State
[16-39] Control Card Temp.
[16-50] External Reference
[16-52] Feedback [Unit]
[16-53] Digi Pot Reference
[16-54] Feedback 1 [Unit]
[16-55] Feedback 2 [Unit]
[16-56] Feedback 3 [Unit]
[16-60] Digital Input
[16-61] Terminal 53 Switch
Setting
[16-62] Analog Input 53
[16-63] Terminal 54 Switch
Setting
[16-64] Analog Input 54
[16-65] Analog Output 42
[mA]
[16-66] Digital Output [bin]
[16-67] Freq. Input #29 [Hz]
[16-68] Freq. Input #33 [Hz]
[16-69] Pulse Output #27
[Hz]
[16-70] Pulse Output #29
[Hz]
[16-71] Pulse Output [bin]
[16-72] Counter A
[16-73] Counter B
[16-75] Analog In X30/11
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 117
