Danfoss vlt aqua Programming Guide

[16-76] Analog In X30/12
[16-77] Analog In X30/8 [mA]
[16-84] Comm Option STW
[16-85] FC port CTW 1
[16-90] Alarm Word
[16-91] Alarm Word 2
[16-92] Warning Word
[16-93] Warning Word 2
[16-94] Extended Status
Word
[16-95] Extended Status
Word 2
[16-96] Prev. Maintenance
Word
9-18 Node Address
Range: Function:
126
*
[0 - 126] Enter the station address in this parameter or alternatively in
the hardware switch. In order to adjust the station address in
par. 9-18, the hardware switch must be set to 126 or 127 (i.e.
all switches set to ‘on’). Otherwise this parameter will display
the actual setting of the switch.
9-22 Telegram Selection
Option: Function:
Select a standard Profibus telegram configuration for the fre-
quency converter, as an alternative to using the freely configu-
rable telegrams in par. 9-15 and 9-16.
[1] Standard telegram 1
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108]
*
PPO 8
9-23 Parameters for Signals
Array [1000]
This parameter contains a list of signals available for selection
in par. 9-15 and 9-16.
None
[3-02] Minimum Reference
2. Parameter Description VLT
®
AQUA Drive Programming Guide
118 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
