Danfoss vlt aqua Programming Guide

[3-03] Maximum Reference
[3-41] Ramp 1 Ramp Up
Time
[3-42] Ramp 1 Ramp Down
Time
[3-51] Ramp 2 Ramp Up
Time
[3-52] Ramp 2 Ramp Down
Time
[3-80] Jog Ramp Time
[3-81] Quick Stop Ramp
Time
[4-11] Motor Speed Low
Limit [RPM]
[4-13] Motor Speed High
Limit [RPM]
[4-16] Torque Limit Motor
Mode
[4-17] Torque Limit Genera-
tor Mode
[5-90] Digital and Relay Bus
Control
[5-93] Pulse Output #27 Bus
Control
[5-95] Pulse Output #29 Bus
Control
[6-53] Terminal 42 Output
Bus Control
[8-90] Bus Jog 1 Speed
[8-91] Bus Jog 2 Speed
[8-94] Bus Feedback 1
[8-95] Bus Feedback 2
[8-96] Bus Feedback 3
[16-00] Control Word
[16-01] Reference [Unit]
[16-02] Reference %
[16-03] Status Word
[16-05] Main Actual Value [%]
[16-09] Custom Readout
[16-10] Power [kW]
[16-11] Power [hp]
[16-12] Motor Voltage
[16-13] Frequency
[16-14] Motor Current
[16-15] Frequency [%]
[16-16] Torque [Nm]
[16-17] Speed [RPM]
[16-18] Thermal Motor Load
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 119
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
