[16-30] DC Link Voltage
[16-32] Brake Energy / s
[16-33] Brake Energy / 2 Min
[16-34] Heatsink Temp.
[16-35] Thermal Drive Load
[16-38] SL Controller State
[16-39] Control Card Temp.
[16-50] External Reference
[16-52] Feedback [Unit]
[16-53] Digi Pot Reference
[16-54 ] Feedback 1 [Unit]
[16-55 ] Feedback 2 [Unit]
[16-56 ] Feedback 3 [Unit]
[16-60 ] Digital Input
[16-61 ] Terminal 53 Switch
Setting
[16-62 ] Analog Input 53
[16-63 ] Terminal 54 Switch
Setting
[16-64 ] Analog Input 54
[16-65 ] Analog Output 42
[mA]
[16-66 ] Digital Output [bin]
[16-67 ] Freq. Input #29 [Hz]
[16-68 ] Freq. Input #33 [Hz]
[16-69 ] Pulse Output #27
[Hz]
[16-70 ] Pulse Output #29
[Hz]
[16-71 ] Relay Outputs [bin]
[16-72 ] Counter A
[16-73 ] Counter B
[16-75 ] Analog In X30/11
[16-76 ] Analog In X30/12
[16-77 ] Analog Out X30/8
[16-80 ] Fieldbus CTW 1
[16-82 ] Fieldbus REF 1
[16-84 ] Comm Option STW
[16-85 ] FC Port CTW 1
[16-90 ] Alarm Word
[16-91 ] Alarm Word 2
[16-92 ] Warning Word
[16-93 ] Warning Word 2
[16-94 ] Extended Status
Word
[16-95] Extended Status
Word 2
