Danfoss vlt aqua Programming Guide

[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Thermal Motor Load
[1622] Torque [%]
[1630] DC Link Voltage
[1632] Brake Energy / s
[1633] Brake Energy / 2 min
[1634] Heatsink Temp.
[1635] Thermal Drive Load
[1650] External Reference
[1652] Feedback [Unit]
[1654] Feedback 1 [Unit]
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1659] Adjusted Setpoint
[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42
[mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8
[mA]
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1820] Analog Input X42/1
[1821] Analog Input X42/3
[1822] Analog Input X42/5
[1823] Analog Out X42/7
[mA]
[1824] Analog Out X42/9
[mA]
2. Parameter Description VLT
®
AQUA Drive Programming Guide
154 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
