Danfoss vlt aqua Programming Guide

15-20 Historic Log: Event
Array [50]
0 *
[0 - 255] View the event type of the logged events.
15-21 Historic Log: Value
Array [50]
0 *
[0 - 2147483647] View the value of the logged event. Interpret the event values
according to this table:
Digtal input Decimal value. See par. 16-60 for description
after converting to binary value.
Digital output (not moni-
tored in this SW release)
Decimal value. See par. 16-66 for description
after converting to binary value.
Warning word Decimal value. See par. 16-92 for description.
Alarm word Decimal value. See par. 16-90 for description.
Status word Decimal value. See par. 16-03 for description
after converting to binary value.
Control word Decimal value. See par. 16-00 for description.
Extended status word Decimal value. See par. 16-94 for description.
15-22 Historic Log: Time
Array [50]
0 *
[0 - 2147483647] View the time at which the logged event occurred. Time is
measured in ms since frequency converter start. The max. value
corresponds to approx. 24 days which means that the count will
restart at zero after this time period.
2.14.5. Fault Log, 15-3*
Parameters in this group are array parameters, where up to 10 fault logs can be viewed. [0] is
the most recent logged data, and [9] the oldest. Error codes, values, and time stamp can be
viewed for all logged data.
15-30 Fault Log: Error Code
Array [10]
0 *
[0 - 255] View the error code and look up its meaning in the Trouble-
shooting
chapter.
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 157
2
