Danfoss vlt aqua Programming Guide

18-30 Analog Input X42/1
Range: Function:
00.0
*
[-20.000 – +20.000] Read out of the value of the signal applied to terminal X42/1 on
the Analog I/O Card.
The units of the value shown in the LCP will correspond to the
mode selected in par.26-00, Terminal X/42-1 Mode.
18-31 Analog Input X42/3
Range: Function:
00.0
*
[-20.000 – +20.000] Read out of the value of the signal applied to terminal X42/3 on
the Analog I/O Card.
The units of the value shown in the LCP will correspond to the
mode selected in par.26-01, Terminal X42/3 Mode.
18-32 Analog Input X42/5
Range: Function:
00.0
*
[-20.000 – +20.000] Read out of the value of the signal applied to terminal X42/5 on
the Analog I/O Card.
The units of the value shown in the LCP will correspond to the
mode selected in par.26-02, Terminal X42/5 Mode.
18-33 Analog Output X42/7
Range: Function:
00.0
*
[0 – 30.000] Read out of the value of the signal applied to terminal X42/7 on
the Analog I/O Card.
The value shown reflects the selection in par. 26-40.
18-34 Analog Output X42/9
Range: Function:
00.0
*
[0 – 30.000] Read out of the value of the signal applied to terminal X42/9 on
the Analog I/O Card.
The value shown reflects the selection in par. 26-50.
18-35 Analog Output X42/11
Range: Function:
00.0
*
[0 – 30.000] Read out of the value of the signal applied to terminal X42/11
on the Analog I/O Card.
The value shown reflects the selection in par. 26-60.
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 173
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
