[16] Select preset ref. 6
[17] Select preset ref. 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set dig. out. A low
[33] Set dig. out. B low
[34] Set dig. out. C low
[35] Set dig. out. D low
[36] Set dig. out. E low
[37] Set dig. out. F low
[38] Set dig. out. A high
[39] Set dig. out. B high
[40] Set dig. out. C high
[41] Set dig. out. D high
[42] Set dig. out. E high
[43] Set dig. out. F high
[60] Reset counter A
[61] Reset counter B
[70] Start timer 3
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7 Select the action during ON Time. See par. 13.52
SL Controller
Action
for descriptions of the options.
23-02 OFF Time
Array [10]
00:00:0
0
*
[00:00:00 –23:59:59] Sets the OFF time for the Timed Action.
