Danfoss vlt aqua Programming Guide

26-60 Terminal X42/11 Output
Option: Function:
Set the function of terminal X42/11 as an analog current output.
[0]
*
No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to lim.
[105] Torque rel to rated
[106] Power
[107] Speed
[108] Torque
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[139] Bus ctrl.
[141] Bus ctrl timeout
26-61 Terminal X42/11 Output Min. Scale
Range: Function:
0%
*
[0.00 - 200%] Scale the minimum output of the selected analog signal at ter-
minal X42/11, as a percentage of the maximum signal level. E.g.
if a 0 mA (or 0 Hz) is desired at 25% of the maximum output
value. Then programme 25%. Scaling values up to 100% can
never be higher than the corresponding setting in par 26-72.
26-62 Terminal X42/11 Output Max. Scale
Range: Function:
100%
*
[0.00 - 200%] Scale the maximum output of the selected analog signal at ter-
minal X42/9. Set the value to the maximum value of the current
signal output. Scale the output to give a current lower than
20mA at full scale; or 20mA at an output below 100% of the
maximum signal value. If 20mA is the desired output current at
a value between 0-100% of the full-scale output, programme
the percentage value in the parameter, i.e. 50% = 20mA. If a
current between 4 and 20mA is desired at maximum output,
calculate the percentage as follows:
20 mA
Desired maximum current
× 100 %
i.e.
10 mA :
20 mA
10 mA
× 100 % = 200 %
