Danfoss vlt aqua Programming Guide

Par. No. # Parameter description Default value 4-set-up Change during opera-
tion
Conver-
sion index
Type
23-0* Timed Actions 23-00 ON Time SR 2 set-ups TRUE 0
TimeOfDay-
WoDate
23-01 ON Action [0] Disabled 2 set-ups TRUE - Uint8
23-02 OFF Time SR 2 set-ups TRUE 0
TimeOfDay-
WoDate
23-03 OFF Action [0] Disabled 2 set-ups TRUE - Uint8
23-04
Occurrence [0] All days 2 set-ups TRUE - Uint8
23-1* Maintenance 23-10 Maintenance Item [1] Motor bearings 1 set-up TRUE - Uint8 23-11 Maintenance Action [1] Lubricate 1 set-up TRUE - Uint8
23-12 Maintenance Time Base [0] Disabled 1 set-up TRUE - Uint8
23-13 Maintenance Time Interval 1 h 1 set-up TRUE 74 Uint32
23-14
Maintenance Date and Time SR 1 set-up TRUE 0 TimeOfDay
23-1* Maintenance Reset 23-15 Reset Maintenance Word [0] Do not reset All set-ups TRUE - Uint8 23-5* Energy Log 23-50 Energy Log Resolution [5] Last 24 Hours 2 set-ups TRUE - Uint8 23-51 Period Start SR 2 set-ups TRUE 0 TimeOfDay
23-53 Energy Log 0 N/A All set-ups TRUE 0 Uint32
23-54 Reset Energy Log [0] Do not reset All set-ups TRUE - Uint8 23-6* Trending 23-60 Trend Variable [0] Power [kW] 2 set-ups TRUE - Uint8 23-61 Continuous Bin Data 0 N/A All set-ups TRUE 0 Uint32 23-62 Timed Bin Data 0 N/A All set-ups TRUE 0 Uint32
23-63 Timed Period Start SR 2 set-ups TRUE 0 TimeOfDay
23-64 Timed Period Stop SR 2 set-ups TRUE 0 TimeOfDay
23-65 Minimum Bin Value SR 2 set-ups TRUE 0 Uint8
23-66 Reset Continuous Bin Data [0] Do not reset All set-ups TRUE - Uint8
23-67
Reset Timed Bin Data [0] Do not reset All set-ups TRUE - Uint8
23-8* Payback Counter 23-80 Power Reference Factor 100 % 2 set-ups TRUE 0 Uint8 23-81 Energy Cost 1.00 N/A 2 set-ups TRUE -2 Uint32
23-82 Investment 0 N/A 2 set-ups TRUE 0 Uint32
23-83 Energy Savings 0 kWh All set-ups TRUE 75 Int32
23-84 Cost Savings 0 N/A All set-ups TRUE 0 Int32
3.1.20. 23-** Timed Actions
VLT
®
AQUA Drive Programming Guide 3. Parameter Lists
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 283
3

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
