Page #84 background imageLoading...
Page #84 background image
5-18 Terminal X30/4 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is instal-
led in the frequency converter.
It has the same options and functions as par. 5-1
Digital In-
puts
, except for
Pulse input
[32].
2.7.4. 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital
outputs are common for terminals 27 and 29. Set the I/O function for terminal 27 in par. 5-01
Terminal 27 Mode
, and set the I/O function for terminal 29 in par. 5-02
Terminal 29 Mode
.
These parameters cannot be adjusted while the motor is running.
The digital outputs can be programmed with these functions:
[0] No operation
Default for all digital outputs and relay outputs
[1] Control ready The control board receives supply voltage.
[2] Drive ready The frequency converter is ready for operation and applies a
supply signal on the control board.
[3] Drive ready / remote
control
The frequency converter is ready for operation and is in Auto
On mode.
[4] Stand-by / no warning The frequency converter is ready for operation. No start or stop
command is been given (start/disable). There are no warnings.
[5] Running Motor is running.
[6] Running / no warning The output speed is higher than the speed set in par. 1-81
Min
Speed for Function at Stop [RPM]
. The motor is running and
there are no warnings.
[8] Run on reference / no
warning
Motor runs at reference speed.
[9] Alarm An alarm activates the output. There are no warnings.
[10] Alarm or warning An alarm or a warning activates the output.
[11] At torque limit The torque limit set in par. 4-16 or par. 1-17 has been exceeded.
[12] Out of current range The motor current is outside the range set in par. 4-18.
[13] Below current, low Motor current is lower than set in par. 4-50.
[14] Above current, high Motor current is higher than set in par. 4-51.
[15] Out of speed range Output speed is outside the range set in par. 4-52 and 4-53.
[16] Below speed, low Output speed is lower than the setting in par. 4-52.
[17] Above speed, high Output speed is higher than the setting in par. 4-53.
[18] Out of feedback range Feedback is outside the range set in par. 4-56 and 4-57.
[19] Below feedback low Feedback is below the limit set in par. 4-56
Warning Feedback
Low.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
84
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
