Danfoss VLT AutomationDrive FC 300 Programming Guide

(par. 5-02 Terminal 29 Mode = input [0] (default) and par. 5-13 Terminal 29 Digital Input = appli-
cable value).
This parameter is available for FC 302 only.
5-53 Term. 29 High Ref./Feedb. Value
Range: Function:
Application
dependent*
[-999999.999 - 999999.999 Refer-
enceFeedbackUnit]
Enter the high reference value [RPM] for the motor shaft speed and the high feedback value, see
also par. 5-58
Term. 33 High Ref./Feedb. Value . Select terminal 29 as a digital input
(par. 5-02
Terminal 29 Mode = input [0] (default) and par. 5-13 Terminal 29 Digital Input = appli-
cable value).
This parameter is available for FC 302 only.
5-54 Pulse Filter Time Constant #29
Range: Function:
100 ms* [1 - 1000 ms] Enter the pulse filter time constant. The pulse filter dampens oscillations of the feedback signal,
which is an advantage if there is a lot of noise in the system. A high time constant value results in
better dampening but also increases the time delay through the filter. This parameter is available
for FC 302 only.
This parameter cannot be adjusted while the motor is running.
5-55 Term. 33 Low Frequency
Range: Function:
100 Hz* [0 - 110000 Hz] Enter the low frequency corresponding to the low motor shaft speed (i.e. low reference value) in
par. 5-57
Term. 33 Low Ref./Feedb. Value .
5-56 Term. 33 High Frequency
Range: Function:
100 Hz* [0 - 110000 Hz] Enter the high frequency corresponding to the high motor shaft speed (i.e. high reference value) in
par. 5-58
Term. 33 High Ref./Feedb. Value .
5-57 Term. 33 Low Ref./Feedb. Value
Range: Function:
0.000 N/A* [-999999.999 - 999999.999 N/A] Enter the low reference value [RPM] for the motor shaft speed. This is also the low feedback value,
see also par. 5-52
Term. 29 Low Ref./Feedb. Value .
5-58 Term. 33 High Ref./Feedb. Value
Range: Function:
Application
dependent*
[-999999.999 - 999999.999 Refer-
enceFeedbackUnit]
Enter the high reference value [RPM] for the motor shaft speed. See also par. 5-53 Term. 29 High
Ref./Feedb. Value
.
5-59 Pulse Filter Time Constant #33
Range: Function:
100 ms* [1 - 1000 ms] Enter the pulse filter time constant. The low-pass filter reduces the influence on and dampens os-
cillations on the feedback signal from the control.
This is an advantage, e.g. if there is a great amount on noise in the system. This parameter cannot
be adjusted while the motor is running.
3 Parameter descriptions FC 300 Programming Guide
110 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
