[0] * No operation When no signal on the analog output.
[52] MCO 0-20mA
[100] Output frequency 0 Hz = 0 mA; 100 Hz = 20 mA.
[101] Reference Par. 3-00
Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Par. 3-00
Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA
[102] Feedback
[103] Motor current Value is taken from par. 16-37
Inv. Max. Current . Inverter max. current (160% current) is equal to
20 mA.
Example: Inverter norm current (11 kW) = 24 A. 160 % = 38.4 A. Motor norm current = 22 A Read-
out 11.46 mA.
20 mA x 22 A
38.4 A
= 11.46 mA
In case the norm motor current is equal to 20 mA, the output setting of par. 6-62 Terminal X30/8
Max. Scale
is:
I
VLT
Max
x 100
I
Motor
Norm
=
38.4 x 100
22
=175%
[104] Torque rel to limit The torque setting is related to setting in par. 4-16 Torque Limit Motor Mode .
[105] Torq relate to rated The torque is related to the motor torque setting.
[106] Power Taken from par. 1-20
Motor Power [kW] .
[107] Speed Taken from par. 3-03
Maximum Reference . 20 mA = value in par. 3-03 Maximum Reference
[108] Torque Torque reference related to 160% torque.
[109] Max Out Freq In relation to par. 4-19
Max Output Frequency .
[113] PID Clamped Output
[119] Torque % lim
[130] Output freq. 4-20mA 0 Hz = 4 mA, 100 Hz = 20 mA
[131] Reference 4-20mA Par. 3-00
Reference Range [Min-Max] 0% = 4 mA; 100% = 20 mA
Par. 3-00
Reference Range [-Max-Max] -100% = 4mA; 0% = 12 mA; +100% = 20 mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA Value is taken from par. 16-37
Inv. Max. Current . Inverter max. current (160% current) is equal to
20 mA.
Example: Inverter norm current (11 kW) = 24 A. 160 % = 38.4 A. Motor norm current = 22 A Read-
out 11.46 mA.
16 mA x 22 A
38.4 A
= 9.17 mA
In case the norm motor current is equal to 20 mA, the output setting of par. 6-62 Terminal X30/8
Max. Scale
is:
I
VLT
Max
x 100
I
Motor
Norm
=
38.4 x 100
22
=175%
[134] Torq.% lim 4-20 mA The torque setting is related to setting in par. 4-16 Torque Limit Motor Mode .
[135] Torq.% nom 4-20 mA The torque setting is related to the motor torque setting.
[136] Power 4-20mA Taken from par. 1-20
Motor Power [kW]
[137] Speed 4-20mA Taken from par. 3-03 Maximum Reference . 20 mA = Value in par. 3-03 Maximum Reference .
[138] Torque 4-20mA Torque reference related to 160% torque.
[139] Bus ctrl. 0-20 mA An output value set from fieldbus process data. The output will work independently of internal
functions in the frequency converter.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 123
3
