Bit: Meaning:
0 Connection with DP-master is not ok
1Not used
2 FDLNDL (Fieldbus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5 Baudrate search
6 PROFIBUS ASIC is not transmitting
7 Initialisation of PROFIBUS is not ok
8 Frequency converter is tripped
9 Internal CAN error
10 Wrong configuration data from PLC
11 Wrong ID sent by PLC
12 Internal error occured
13 Not configured
14 Timeout active
15 Warning 34 active
9-63 Actual Baud Rate
Option: Function:
This parameter displays the actual Profibus baud rate. The Profibus Master automatically sets the
baud rate.
[0] 9,6 kbit/s
[1] 19,2 kbit/s
[2] 93,75 kbit/s
[3] 187,5 kbit/s
[4] 500 kbit/s
[6] 1500 kbit/s
[7] 3000 kbit/s
[8] 6000 kbit/s
[9] 12000 kbit/s
[10] 31,25 kbit/s
[11] 45,45 kbit/s
[255] * No baudrate found
9-64 Device Identification
Range: Function:
0* [0 - 0 ] This parameter displays the device identification. Please refer to the
Operating Instructions for Pro-
fibus,
MG.33.CX.YY for further explanation.
9-65 Profile Number
Range: Function:
0 N/A* [0 - 0 N/A] This parameter contains the profile identification. Byte 1 contains the profile number and byte 2 the
version number of the profile.
NB!
This parameter is not visible via LCP.
3 Parameter descriptions FC 300 Programming Guide
158
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
