Danfoss VLT AutomationDrive FC 300 Programming Guide

[52] Control ready Control ready [52] The control board receives supply voltage
[53] Drive ready
Drive ready [53] The frequency converter is ready for operation and applies a supply signal on the
control board.
[54] Running
Running [54] The motor is running.
[55] Reversing
Reversing [55] The output is high when the frequency converter is running counter clockwise (the
logical product of the status bits “running” AND “reverse”)
[56] In range
In range [56] The motor is running within the programmed current and speed ranges set in
par. 4-50
Warning Current Low to par. 4-53 Warning Speed High .
[60] On reference
On reference [60] The motor is running on reference.
[61] Below reference, low
Below reference, low [61] The motor is running below the value given in par. 4-54 Warning Refer-
ence Low
[62] Above ref, high Above reference, high [62] The motor is running above the value given in par. 4-55 Warning Ref-
erence High
[65] Torque limit Torque limit [65] The torque limit, set in par. 4-16 Torque Limit Motor Mode or par. 4-17 Torque
Limit Generator Mode
, has been exceeded.
[66] Current limit
Current limit [66] The motor current limit, set in par. 4-18 Current Limit , has been exceeded.
[67] Out of current range
Out of current range [67] The motor current is outside the range set in par. 4-18 Current Limit .
[68] Below I low
Below I low [68] The motor current is lower than set in par. 4-50 Warning Current Low .
[69] Above I high
Above I high [69] The motor current is higher than set in par. 4-51 Warning Current High .
[70] Out of speed range
Out of speed range [70] The speed is outside the range set in par. 4-52 Warning Speed Low and
par. 4-53
Warning Speed High .
[71] Below speed low
Below speed low [71] The output speed is lower than the setting in par. 4-52 Warning Speed Low .
[72] Above speed high
Above speed high [72] The output speed is higher than the setting in par. 4-53 Warning Speed
High
.
[75] Out of feedb. range
Out of feedb. Range [75] The feedback is outside the range set in par. 4-56 Warning Feedback
Low
and par. 4-57 Warning Feedback High .
[76] Below feedb. low
Below feedb. Low [76] The feedback is below the limit set in par. par. 4-56 Warning Feedback
Low
.
[77] Above feedb. high
Above feedb. High [77] The feedback is above the limit set in par. 4-57 Warning Feedback High .
[80] Thermal warning
Thermal warning [80] The thermal warning turns on when the temperature exceeds the limit in the
motor, the frequency converter, the brake resistor or thermistor.
[82] Mains out of range
Mains out of range [82] The mains voltage is outside the specified voltage range.
[85] Warning
Warning [85] A warning is active.
[86] Alarm (trip)
Alarm (trip) [86] A (trip) alarm is active.
[87] Alarm (trip lock)
Alarm (trip lock) [87] A (Trip lock) alarm is active.
[90] Bus OK
Bus OK [90] Active communication (no time-out) via the serial communication port.
[91] Torque limit & stop
Torque limit & stop [91] If the frequency converter has received a stop signal and is at the torque
limit, the signal is logic “0”.
[92] Brake fault (IGBT)
Brake fault (IGBT) [92] The brake IGBT is short circuited.
[93] Mech. brake control
Mech. brake control [93] The mechanical brake is active.
[94] Safe stop active
[100] Comparator 0
Comparator 0 [100] The result of comparator 0.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 181
3
