Danfoss VLT AutomationDrive FC 300 Programming Guide

[101] Comparator 1 Comparator 1 [101] The result of comparator 1.
[102] Comparator 2
Comparator 2 [102] The result of comparator 2.
[103] Comparator 3
Comparator 3 [103] The result of comparator 3.
[104] Comparator 4
Comparator 4 [104] The result of comparator 4.
[105] Comparator 5
Comparator 5 [105] The result of comparator 5.
[110] Logic rule 0
Logic rule 0 [110] The result of Logic rule 0.
[111] Logic rule 1
Logic rule 1 [111] The result of Logic rule 1.
[112] Logic rule 2
Logic rule 2 [112] The result of Logic rule 2.
[113] Logic rule 3
Logic rule 3 [113] The result of Logic rule 3.
[114] Logic rule 4
Logic rule 4 [114] The result of Logic rule 4.
[115] Logic rule 5
Logic rule 5 [115] The result of Logic rule 5.
[120] SL Time-out 0
SL Time-out 0 [120] The result of SLC timer 0.
[121] SL Time-out 1
SL Time-out 1 [121] The result of SLC timer 1.
[122] SL Time-out 2
SL Time-out 2 [122] The result of SLC timer 2.
[123] SL Time-out 3
SL Time-out 3 [123] The result of SLC timer 3.
[124] SL Time-out 4
SL Time-out 4 [124] The result of SLC timer 4.
[125] SL Time-out 5
SL Time-out 5 [125] The result of SLC timer 5.
[126] SL Time-out 6
SL Time-out 6 [126] The result of SLC timer 6.
[127] SL Time-out 7
SL Time-out 7 [127] The result of SLC timer 7.
[130] Digital input DI18
Digital input DI18 [130] Digital input 18. High = True.
[131] Digital input DI19
Digital input DI19 [131] Digital input 19. High = True.
[132] Digital input DI27
Digital input DI27 [132] Digital input 27. High = True.
[133] Digital input DI29
Digital input DI29 [133] Digital input 29. High = True.
[134] Digital input DI32
Digital input DI32 [134] Digital input 32. High = True.
[135] Digital input DI33
Digital input DI33 [135] Digital input 33. High = True.
[150] SL digital output A
SL digital output A [150] Use the result of the SLC output A.
[151] SL digital output B
SL digital output B [151] Use the result of the SLC output B.
[152] SL digital output C
SL digital output C [152] Use the result of the SLC output C.
[153] SL digital output D
SL digital output D [153] Use the result of the SLC output D.
[154] SL digital output E
SL digital output E [154] Use the result of the SLC output E.
[155] SL digital output F
SL digital output F [155] Use the result of the SLC output F.
[160] Relay 1
Relay 1 [160] Relay 1 is active
[161] Relay 2
Relay 2 [161] Relay 2 is active
[180] Local ref. active
Local ref. active [180] High when par. 3-13 Reference Site = [2] Local or when par. 3-13 Reference
Site
is [0] Linked to hand Auto, at the same time as the LCP is in Hand on mode.
[181] Remote ref. active
Remote ref. active [181] High when par. 3-13 Reference Site = [1] Remote or [0] Linked to hand/
auto, while the LCP is in Auto on mode.
[182] Start command
Start command [182] High when there is an active start command, and no stop command.
3 Parameter descriptions FC 300 Programming Guide
182 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
