[1625] Torque [Nm] High
[1630] DC Link Voltage Intermediate circuit voltage in the frequency converter.
[1632] Brake Energy /s Present brake power transferred to an external brake resistor.
Stated as an instantaneous value.
[1633] Brake Energy /2 min Brake power transferred to an external brake resistor. The mean power is calculated continuously
for the most recent 120 seconds.
[1634] Heatsink Temp. Present heat sink temperature of the frequency converter. The cut-out limit is 95 ±5 oC; cutting
back in occurs at 70 ±5° C.
[1635] Inverter Thermal Percentage load of the inverters.
[1636] Inv. Nom. Current Nominal current of the frequency converter.
[1637] Inv. Max. Current Maximum current of the frequency converter.
[1638] SL Controller State State of the event executed by the control.
[1639] Control Card Temp. Temperature of the control card.
[1650] External Reference Sum of the external reference as a percentage, i.e. the sum of analog/pulse/bus.
[1651] Pulse Reference Frequency in Hz connected to the digital inputs (18, 19 or 32, 33).
[1652] Feedback [Unit] Reference value from programmed digital input(s).
[1653] Digi Pot Reference
[1660] Digital Input Signal states form the 6 digital terminals (18, 19, 27, 29, 32 and 33). There are 16 bits in total, but
only six of them are used. Input 18 corresponds to the leftmost of the used bits. Signal low = 0;
Signal high = 1.
[1661] Terminal 53 Switch Setting Setting of input terminal 54. Current = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a reference or protection value.
[1663] Terminal 54 Switch Setting Setting of input terminal 54. Current = 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as reference or protection value.
[1665] Analog Output 42 [mA] Actual value at output 42 in mA. Use par. 6-50
Terminal 42 Output
to select the value to be shown.
[1666] Digital Output [bin] Binary value of all digital outputs.
[1667] Freq. Input #29 [Hz] Actual value of the frequency applied at terminal 29 as an impulse input.
[1668] Freq. Input #33 [Hz] Actual value of the frequency applied at terminal 33 as an impulse input.
[1669] Pulse Output #27 [Hz] Actual value of impulses applied to terminal 27 in digital output mode.
[1670] Pulse Output #29 [Hz] Actual value of impulses applied to terminal 29 in digital output mode.
[1671] Relay Output [bin]
[1672] Counter A Application dependent (e.g. SLC Control)
[1673] Counter B Application dependent (e.g. SLC Control)
[1674] Prec. Stop Counter Display the actual counter value.
[1675] Analog In X30/11 Actual value at input X30/11 either as reference or protection value.
[1676] Analog In X30/12 Actual value at input X30/12 either as reference or protection value.
[1677] Analog Out X30/8 [mA] Actual value at output X30/8 in mA. Use par. 6-60
Terminal X30/8 Output
to select the value to be
shown.
[1678] Analog Out X45/1 [mA]
[1679] Analog Out X45/3 [mA]
[1680] Fieldbus CTW 1 Control word (CTW) received from the Bus Master.
3 Parameter descriptions FC 300 Programming Guide
36
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
